Westin 58-41025 Installation Instructions Manual

ITEM QUANTITY
1 1
2 1
3 2
4 1
5 1
6 1
7 1
8 1
9 6
10 1
11 1
12 1
13 1
14 1
15 1
16 1
17 2
18 6
19 10
20 10
21 20
22 20
23 6
24 6
25 6
26 6
27 6
28 6
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-5841025-RevA ECO #: W18-0229
INSTALLATION INSTRUCTIONS
PRO-MOD FRONT BUMPER
APPLICATION:
2013-2018 Ram 1500; 2019 Ram 1500 Classic
PART NUMBER:
58-41025
CONTENT
DESCRIPTION
DRIVER SIDE POD ASSEMBLY
PASSENGER SIDE POD ASSEMBLY
MESH COVER PLATE
CENTER SECTION
VALANCE SKID PLATE
DRIVER MOUNTING BRACKET
PASSENGER MOUNTING BRACKET
M10 NUT PLATE
SENSOR TAB
M10 BOLT PLATE
DRIVER SIDE STRAP
PASSENGER SIDE STRAP
DRIVER VALANCE MOUNT BRACKET
PASSENGER VALANCE MOUNT BRACKET
DRIVER FILLER TRIANGLE
PASSENGER FILLER TRIANGLE
LED BRACKET
HOLE PLUG
M12 HEX HEAD BOLT (YELLOW ZINC)
M12 HEX NUT (YELLOW ZINC)
M12 FLAT WASHER (YELLOW ZINC)
M12 SPLIT LOCK WASHER (YELLOW ZINC)
M6 CARRIAGE BOLT (YELLOW ZINC)
M6 SPLIT LOCK WASHER (YELLOW ZINC)
M6 HEX NUT (YELLOW ZINC)
M6 FLAT WASHER (YELLOW ZINC)
M10 HEX HEAD BOLT (YELLOW ZINC)
M10 SPLIT LOCK WASHER (YELLOW ZINC)
1
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
10MM SOCKET
10MM WRENCH
13MM SOCKET
13MM WRENCH
16MM SOCKET
16MM WRENCH
18MM SOCKET
19MM WRENCH
RATCHET
TORQUE WRENCH
DATE: 04/15/19
