Westin HDX GRILLE GUARD Installation Instructions Manual

ITEM QUANTITY
1 1
2 1
3 1
4 1
5 1
6 4
7 8
8 4
9 4
10 6
11 6
12 6
13 2
14 2
15 1
16 1
17 1
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
* These parts belong to the license plate relocation kit (sold separately) Part number 32-0055
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-57402-RevA ECO #: W19-0106
INSTALLATION INSTRUCTIONS
APPLICATION:
2019 Dodge Ram 2500/3500
PART NUMBER:
57-4020, 57-4025
CONTENT
DRIVER MOUNTING BRACKET
PASSENGER MOUNTING BRACKET
UPPER DRIVER STRAP
UPPER PASSENGER STRAP
M12 HEX HEAD BOLT
M12 LOCK WASHER
M12 SOCKET BUTTON HEAD BOLT
M12 SERRATED BELLILLE WASHER
M12 SERRATED FLANGE NUT
M12 PLASTIC RETAINER
M12 PLASTIC RETAINER SQUARE
M6 BUTTON HEAD BOLT *
M6 FLAT WASHER *
M6 SPRING LOCK WASHER *
ITEM 1
HDX GRILLE GUARDS
DESCRIPTION
GRILLE GUARD
M12 FLAT WASHER
M12 HEX NUT
for additional installation assistance please call
1
TOOLS NEEDED
18MM WRENCH
TORQUE WRENCH
CUTTING TOOL
HDX G.G.
Thank you for choosing Westin products
Customer Service (800) 793-7846
www.westinautomotive.com
18MM SOCKET
ALLEN
RATCHET
DATE: 9/5/19
