Westin PROMOD FRONT BUMPER Installation Instructions Manual

ITEM QUANTITY
1 2
2 2
3 1
4 2
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 12
14 12
15 12
16 12
17 2
18 2
19 2
20 2
21 6
22 6
23 12
24 6
25 16
26 12
27 16
28 28
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-5841205-RevA ECO #: W19-0025
INSTALLATION INSTRUCTIONS
APPLICATION:
2011-2016 Ford F-250/350/450/550 Super Duty
PART NUMBER:
58-41205
CONTENT
DESCRIPTION
SIDE POD ASSEMBLY (1 DRIVER, 1 PASSENGER)
MESH SIDE COVERS (1 DRIVER, 1 PASSENGER)
CENTER SECTION
LED LIGHT BRACKET
DRIVER MOUNTING BRACKET
PASSENGER MOUNTING BRACKET
UPPER PASSENGER SUPPORT BRACKET
UPPER DRIVER SUPPORT BRACKET
DRIVER SIDE STRAP
PASSENGER SIDE STRAP
LOWER DRIVER SUPPORT BRACKET
LOWER PASSENGER SUPPORT BRACKET
M6 BUTTON HEAD BOLT (BLACK ZINC)
M6 FLAT WASHER (BLACK ZINC)
M6 SERRATED FLANGE NUT (BLACK ZINC)
M6 LOCK WASHER (BLACK ZINC)
M10 HEX HEAD BOLT (BLACK ZINC)
M10 SPLIT LOCK WASHER (BLACK ZINC)
M10 FLAT WASHER (BLACK ZINC)
M10 HEX NUT (BLACK ZINC)
M8 BUTTON HEAD BOLT (BLACK ZINC)
M8 SPLIT LOCK WASHER (BLACK ZINC)
M8 FLAT WASHERS (BLACK ZINC)
M8 HEX NUT (BLACK ZINC)
M12 SERRATED FLANGE NUT (YELLOW ZINC)
M12 HEX BOLT (YELLOW ZINC)
M12 SPLIT LOCK WASHER (YELLOW ZINC)
M12 FLAT WASHER (YELLOW ZINC)
1
PROMOD FRONT BUMPER
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
4MM ALLEN
10MM WRENCH
13MM SOCKET
13MM WRENCH
17MM SOCKET
17MM WRENCH
19MM SOCKET
19MM WRENCH
RATCHET
TORQUE WRENCH
5MM ALLEN
DATE: 06/25/19
