Westin PRO Series Installation Instructions Manual

ITEM QUANTITY
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 3
11 2
12 4
13 4
14 8
15 8
16 3
17 3
18 3
19 3
20 6
21 12
22 36
23 18
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
1. Remove contents from box, verify if all parts listed are present and free from damage.
Carefully read and understand all instructions before attempting installation.
Failure to identify damage before installation could lead to a rejection of any claim.
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-58411045-RevA ECO #: W20-0088
INSTALLATION INSTRUCTIONS
PRO-SERIES FRONT BUMPER
APPLICATION: 2016-2020 Toyota Tacoma
PART NUMBER: 58-411045
CONTENT
DESCRIPTION
PRO SERIES FRONT BUMPER
WINCH TRAY
LED LIGHT COVER
DRIVER LED LIGHT BRACKET
PASSENGER LED LIGHT BRACKET
DRIVER SUPPORT BRACKET
PASSENGER SUPPORT BRACKET
DRIVER MAIN BRACKET
PASSENGER MAIN BRACKET
RELOCATION BRACKET
RUBBER TRIM
M6 COUNTERSUNK HEX HEAD SCREW
M6 BUTTON HEAD BOLT
M6 FLAT WASHER
M6 SERRATED FLANGE NUT
M8 HEX HEAD BOLT
M8 LOCK WASHER
M8 FLAT WASHER
M8 SERRATED FLANGE NUT
M12 LONG HEX HEAD BOLT
M12 SHORT HEX HEAD BOLT
M12 FLAT WASHER
M12 SERRATED FLANGE NUT
PROCEDURE
1
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
13MM SOCKET
14MM SOCKET
RATCHET
TORQUE WRENCH
10MM SOCKET
CUTTING TOOL
RULER
MARKER
PRY TOOL
GRINDER
CUT OFF WHEEL
DATE: 01/13/2021
