Westin 58-41075 Installation Instructions Manual

ITEM QUANTITY
1 2
2 2
3 1
4 1
5 1
6 1
7 1
8 1
9 6
10 6
11 10
12 10
13 20
14 10
15 6
16 6
17 6
18 12
19 6
20 12
21 6
22 6
23 12
24 12
25 4
26 12
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
Westin Automotive Products, Inc.
320 W. Covina Blvd
San Dimas, Ca. 91773
P.N. 75-5841075-RevA
ECO #: W18-0236

INSTALLATION INSTRUCTIONS

APPLICATION:
2019 Ram 1500 (Excl. 2019 Ram 1500 Classic; Rebel)
PART NUMBER:
58-41075
CONTENT
DESCRIPTION
SIDE POD ASSEMBLY (1 DRIVER, 1 PASSENGER)
MESH SIDE COVERS (1 DRIVER, 1 PASSENGER)
CENTER SECTION
LED LIGHT BRACKET
DRIVER MOUNTING BRACKET
PASSENGER MOUNTING BRACKET
PASSENGER SUPPORT BRACKET
DRIVER SUPPORT BRACKET
HOLE PLUG
SENSOR TAB
M12 HEX HEAD BOLT (YELLOW ZINC)
M12 HEX NUT (YELLOW ZINC)
M12 FLAT WASHER (YELLOW ZINC)
M12 SPLIT LOCK WASHER (YELLOW ZINC)
M6 CARRIAGE BOLT (YELLOW ZINC)
M6 SPLIT LOCK WASHER (YELLOW ZINC)
M6 HEX NUT (YELLOW ZINC)
M6 FLAT WASHERS (YELLOW ZINC)
M10 SPLIT LOCK WASHER (BLACK ZINC)
M10 FLAT WASHER (BLACK ZINC)
M10 HEX HEAD BOLT (BLACK ZINC)
M10 HEX NUT (BLACK ZINC)
M6 FLAT WASHER (BLACK ZINC)
M6 SPLIT LOCK WASHER (BLACK ZINC)
M6 BUTTON HEAD BOLT (BLACK ZINC)
M6 SERRATED FLANGE NUT (BLACK ZINC)
1
PRO-MOD BUMPER
Thank you for choosing Westin products
for additional installation assistance please call
Customer Service (800) 793-7846
www.westinautomotive.com
TOOLS NEEDED
10MM SOCKET
10MM WRENCH
13MM SOCKET
13MM WRENCH
16MM SOCKET
16MM WRENCH
18MM SOCKET
19MM WRENCH
RATCHET
TORQUE WRENCH
DATE: 02/27/19
