height-adjustable bench
Section:
METAL GABLES & CABLE CHANNEL
INSTALL BRACKET
8
8
10
STEP 1: Attach Bracket to stretcher bar using Screws provided.
Installation Guides
11
INSTALL FRAME LINK
NOTE: Refer to HABN_101 for
installation steps for the Frame Link
STEP 2: Install Frame Link to join both frames.
NOTE: Refer to HABN_101 for installation steps. Frame Link must be ordered
seperately.
Date: Sept 2019
Page: 3 of 6
HABN_225f
Rev. 00
