height adjustable bench
Section:
FRAMES & WORKSURFACE
ATTACH TOP BRACKET TO INTERPRET FRAME
Interpret Frame
STEP 1: Using Interpret Frame Nuts, fasten Top Bracket to Center Beam of Interpret Frame,
as shown.
Center Beam
1
Installation Guides
PLACE BOTTOM BRACKET IN PLACE
1
2
NOTE: DO NOT fully tighten nuts
STEP 2: Place Bottomg Bracket in plscce by inserting Top Bracket studs into Bottom Bracket
slots. Fasten Nuts prodvided but DO NOT fully tighten.
Date: May 2019
Page: 3 of 5
HABN_122
4
