IF MOUNTING TO THE ULTRA WALL TRACK
MOUNT ULTRA TRACK TO WALL
MOUNT ULTRA TRACK TO WALL
• Remove small socket head cap screw in the top center of
• Remove small socket head cap screw in the top
the Wall Track. Remove plastic cover.
center of the Wall Track. Remove plastic cover.
• Locate the wall stud and mark the top hole of the Wall Track.
• Locate the wall stud and mark the top hole of the
• Drill 11/64 pilot hole, insert #14 screw and tighten slightly.
Wall Track.
Use a level, mark the lower holes, drill pilot holes and then insert
• Drill 11/64 pilot hole, insert #14 screw and tighten
the #14 screws.
slightly. Use a level, mark the lower holes, drill
pilot holes and then insert the #14 screws.
NOTE: #14 wood screws are supplied with unit. If installing into
metal studs you will need to replace these with proper metal
NOTE: #14 Wood screws are supplied with unit. If installing into
stud fasteners or the provided snap togglers. All hardware used
metal studs, you will need to replace these with proper metal
stud fasteners
to secure track mount must have a proper countersunk head.
ATTACH SLIDER TO ULTRA TRACK
• Insert slider into wall track.
• Insert slider into
• Replace the plastic cover
wall track.
and small socket
• Replace the
head cap screw.
small socket
head cap
screw and
plastic cover.
IF MOUNTING TO A DESK
ADJUST SLIDER POSITION
• Drill a 3/8" hole through the
horizontal mounting surface.
• Screw stud into base of desk mount.
• Push the stud on the desk mount
through the hole.
• Slide the large mounting washer
over the stud from underneath.
• Secure in place with 3/8" nylock nut.
Desk Mount
Stud
Part Number
Length
D0
3.50"
D1
3.50"
D3
5.50"
D5
7.50"
D7
10.50"
Page 1
Page 1 of 4
ULTRA ARM INSTALLATION
ADJUST SLIDER POSITION
STANDARD
Adjust slider to desired height. Tighten slider using adjustment knob.
Maximum
Desk Thickness
Screw stud
2.47"
into desk mount
1.87"
1.87"
1.87"
2.38"
ADJUST SLIDER POSITION
ADJUST SLIDER POSITION
STANDARD
STANDARD
STANDARD
Adjust slider to desired height. Tighten slider using adjustment knob.
Adjust slider to desired height. Tighten slider using adjustment knob.
ADJUST SLIDER POSITION
STANDARD
INVERTED
INVERTED
INVERTED
INVERTED
Once you have
adjusted the slider
to the desired height,
Adjust slider to desired height. Tighten slid
tighen down the Track
Slider using the knob
on the slider as shown.
Desk
Washer
ULTRA ARM INSTALLATION - 5/21/20
INVE
Desk
Nylock
