ENERGY KINETICS System 2000 Frontier Instructions Manual page 17

Replacement Parts
Obtain replacement parts from your local Energy Kinetics dealer.
Contact Energy Kinetics at 800-323-2066 or
for help locating your nearest authorized dealer.
HOT WATER ITEMS
PART NO. DESCRIPTION
10-0416 #14 Plate Heat Exchanger (EK1)
10-0435 #18 Plate Heat Exchanger (EK2)
10-0430C 006 Cartridge for Smart Pump
10-0650 Scale Stopper Kit
10-0650-C Replacement Cartridge for Scale Stopper
10-0423-12 40 Gal. Standard Glass Lined Tank 12 Yr
10-0425-12 40 Gal Lo-Boy Std Glass Lined Tank 12 Yr
10-0424-12 80 Gal Standard Glass Lined Tank 12 Yr
10-0426 120 Gal Standard Glass Lined Tank 6 Yr
B1-17
www.energykinetics.com
FRONTIER REPLACEMENT PARTS
EK1
ITEM
PART NO.
A 10-0710
B 10-0394
C 10-0712
D 10-0713
F 10-0715
G 10-0720
H 10-0721
J 10-0722
K 10-0723
L 10-0716
M 10-0724
N 10-0725
P 10-0726
-- 10-0717
-- 10-0416F
PART NO.
10-0418D
10-0434H
10-0412A
10-0178
10-0412B
10-0415
10-0417F-16
10-0432C
10-0438C
10-0465
10-0516
10-0420
10-0150
10-0933
10-0132
10-0904
EK2
DESCRIPTION
PART NO.
10-0810 Combustion Chamber
10-0395 Energy Converter (Frontier)
10-0812 Front Chamber Liner
10-0713 Rear Chamber Liner (PacMan)
10-0715 Front Insulation Board 2"
10-0820 Front Cover w/Studs
10-0821 Left Jacket
10-0822 Right Jacket
10-0823 Top Jacket
10-0816 Rear Insulation Board 2"
10-0824 Rear Cover
10-0725 Side Jacket Clip
10-0726 Door Hinge Assembly (ea.)
10-0698 Amulet ceramic sleeve
10-0435F Plate Heat Exchanger
ITEMS NOT SHOWN
DESCRIPTION
Digital Manager
Air Vent, ¾"
Plug-In Relay
Puff Switch
Relay Board inside Junction Box
Limit Aquastat (WR 11D18-018)
Digital Temperature Sensor
007 Cartridge (EK1 Main Circ – C.I.)
0010 Cartridge (EK2 Main Circ – C.I.)
Primary Control w/Oil Valve On-Delay
Boiler Pressure Relief Valve 30 psi
T&P Gauge
¾ Two Wire Zone Valve (Std.)
Cartridge for Smart Filter
Flexible Oil Line
Filter Bracket w/Mounting Hardware
