Table 4 Panel Ports and Buttons (continued)
LABEL
LAN1 ~ LAN4
2.5G LAN
10G LAN
PHONE1/2
RESET
POWER
WPS
WLAN
Transceiver Installation
Use the following steps to install an SFP transceiver.
Locate the transmit (Tx) and the receive (Rx) markings on the SFP+ module to identify the top.
1
Insert the transceiver into the slot.
2
Press the transceiver firmly until it clicks into place.
3
The Zyxel Device automatically detects the installed transceiver. Check the LEDs to verify that it is
4
functioning properly.
Close the transceiver's latch (the latch styles vary).
5
Connect the fiber optic cables to the transceiver.
6
Transceiver Removal
Use the following steps to remove an SFP transceiver.
Disconnect the fiber optic cables from the transceiver.
1
Open the transceiver's latch (the latch styles vary).
2
Pull the transceiver out of the slot.
3

1.5.3 WPS Button

You can use the WPS button to quickly set up a secure wireless connection between the Zyxel Device
and a WPS-compatible client by adding one device at a time.
To activate WPS:
Make sure the POWER LED is on and not blinking.
1
Press the WPS button for 1 second (EX5501-B0) / 5 seconds (AX7501-B0 / PX7501-B0) and release it.
2
Chapter 1 Introducing the Zyxel Device
DESCRIPTION
Connect computers or other Ethernet devices to Ethernet ports for Internet access.
Connect analog phones to the PHONE ports to make phone calls.
Press the button to return the Zyxel Device to the factory defaults.
Connect the power adapter and press the ON/OFF button to start the device.
Press the WPS button for more than 1 second (EX5501-B0) / 5 seconds (AX7501-B0 / PX7501-B0) to
quickly set up a secure wireless connection between the device and a WPS-compatible client.
Press the WLAN button for more than 1 second (EX5501-B0) / 2 seconds (AX7501-B0 / PX7501-B0) to
enable the wireless function.
EX5501-B0 / AX7501-B0 / PX7501-B0 User's Guide
25
