PRODUCT NAME: Lauren Bookshelf
ITEM NUMBER: WV005
ASSEMBLED DIMENSIONS : 66"H x 12.25"W x 10"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 9-4-2020
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA
Page 1 of 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ballard Designs Lauren WV005
Summary of Contents for Ballard Designs Lauren WV005
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Lauren Bookshelf ITEM NUMBER: WV005 ASSEMBLED DIMENSIONS : 66”H x 12.25”W x 10”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE.
-
Page 2: Required Tools
Assemble in location for intended use. Ltr. Qty. Hardware Included Allen Bolts REQUIRED TOOLS: 1/4” x 18T x 1 1/4” Allen Wrench (included), Level, Flat Washers Pencil 1/4” See page 5 for others that may be required. Lock Washers 1/4” -Two person assembly suggested. - Page 3 Loaded Bookshelf may be heavy. Optimal support provided when unit is attached directly to a *Wall Stud. If this is not possible, refer to page 5 for using included Expansion Bolts. STEP 1: Before assembling Bookshelf, select location for installion and use Frame (I) as a template to mark wall.
- Page 4 STEP 3: Attach assembled Bookshelf to wall at pre-marked location. Wall Stud: If installation location is centered on a wall stud, place Bookshelf on wall, align holes with marks on wall and drive Wood Screws (G) with 4mm Flat Washer (H) directly into stud. Open Drywall (no Wall Stud present): Refer to Page 5 for installing Expansion Bolts (F).
- Page 5 INSTALLATION / HANGING HARDWARE REQUIRED TOOLS: Qty. Hardware Included - Hammer Wood Screws 4 x 40mm - Phillips Screwdriver (For use when Wall Stud is present) - Level - Pencil Expansion Bolts M5 x 52mm - Drill with 3/8” bit (For use in open drywall.
