Ballard Designs Gentilly WV007 Assembly Instructions

Decorative shelf

PRODUCT NAME: Gentilly Decorative Shelf

ITEM NUMBER: WV007

ASSEMBLED DIMENSIONS : 30"H x 30"W x 8"D

PRODUCTS ARE NOT INTENDED

FOR COMMERCIAL USE.

UPDATED: 9-28-2020

Prevent accidentally discarding small parts or

hardware. Retain all carton contents until assembly

and installation are complete.

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

MADE IN CHINA

Page 1 of 4

Table of Contents

Need help?

Do you have a question about the Gentilly WV007 and is the answer not in the manual?

Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Gentilly Decorative Shelf ITEM NUMBER: WV007 ASSEMBLED DIMENSIONS : 30”H x 30”W x 8”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE.
Page 2 Assemble in location for intended use. Hardware Packet REQUIRED TOOLS: Phillips Screwdriver, Pencil, Level, Drill with 3/8” bit -Two person assembly suggested. Remove all parts, hardware and protective packaging from carton and carefully arrange on a clean, level, padded surface. Ltr.
Page 3 Fig. 2 INSTALLING EXPANSION BOLTS Drywall 3/8” Drill Bit Teeth Tap in Bolt until teeth sink into wall surface. Create Pilot Hole Barrel Turn screw clockwise until it begins to slip. Back out approximately 1/4 inch. STEP 2: Carefully lift Shelf (C) and fit Keyhole over Screw/Bolt Heads then pull/push down to lock. Customer Service: 800-367-2810 Online: www.ballarddesigns.com Page 3 of 4...
Page 4 How to Create a Template for Keyhole Brackets Place a strip of Painter’s Tape over both Keyholes on back of item to be hung. Use a Screwdriver or other pointed tool to punch a hole in tape at TOP of each Keyhole. PAINTER’S TAPE OF KEYHOLE Use a Level and Pencil to mark wall at installation location.
