PRODUCT NAME: Marloe Glass *Shelf
ITEM NUMBER: WV025
ASSEMBLED DIMENSIONS : 52 1/2"H x 36"W x 12"D (4 Shelves)
*Unit may be assembled using 4, 3 or 2 Glass Shelves. See NOTICE at top of PAGE 3.
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 5-22-2024
37 1/2"H x 36"W x 12"D (3 Shelves)
22"H x 36"W x 12"D (2 Shelves)
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN INDIA
