www.teknikoffice.co.uk
Wide Bookcase
Hampstead Park Collection | Model 5420282
Teknik
The stories of your life.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wide Bookcase 5420282 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teknik Wide Bookcase 5420282

Summary of Contents for Teknik Wide Bookcase 5420282

  • Page 1 Teknik The stories of your life. Wide Bookcase Hampstead Park Collection | Model 5420282 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-18 Hammer Not actual size Français 19-21 Español 22-24 Skip the power trip. Safety 25-26 This time. Warranty Page 2...

  • Page 3: Part Identification

    Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. RIGHT END (1) LEFT END (1) TOP (1)

  • Page 4: Hardware Identification

    Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. LONG WOOD SHORT WOOD HIDDEN CAM - 32 CAM SCREW - 32 DOWEL - 32 DOWEL - 4 UPPER GUIDE - 4 LOWER GUIDE - 4 DOOR HANDLE - 2 METAL PIN - 4 RUBBER SLEEVE - 4...
  • Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty carton to å avoid scratching your unit or the fl oor. Push thirty-two HIDDEN CAMS (1) into the TOP (C), BOTTOM (D), å SHELVES (E, F, and G), SKIRTS (I), and FEET (J and K). Arrow (32 used) Arrow...
  • Page 6 Step 2 Turn thirty-two CAM SCREWS (2) into the exact holes shown å in the ENDS (A and B), BOTTOM (D), and FEET (J and K). (32 used) Page 6...
  • Page 7 Step 3 Insert thirty-two LARGE WOOD DOWELS (3) into the å exact holes shown in the edges of the ENDS (A and B), Some assembly TOP (C), BOTTOM (D), SHELVES (E, F, and G), SKIRTS (I), (and snacks) required. and FEET (J and K). (32 used) Page 7...
  • Page 8 Step 4 Fasten the SKIRTS (I) to the FEET (J and K). Tighten four å HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the SKIRTS insert å into the FEET. Surface with HIDDEN CAMS Edge with WOOD DOWELS Page 8...
  • Page 9 Step 5 Fasten the SKIRTS (I) and FEET (J and K) to the BOTTOM (D). å Tighten eight HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the SKIRTS and FEET å insert into the BOTTOM. D E N H I D i t h f a c S u r...
  • Page 10 Step 6 Fasten the TOP MOLDING (L) to the TOP (C). Use four å BLACK 1-1/4" FLAT HEAD SCREWS (12). NOTE: Do not over tighten the SCREWS into the TOP. å BLACK 1-1/4" FLAT HEAD SCREW Finished edge (4 used in this step) Page 10...
  • Page 11 Step 7 Insert two SMALL WOOD DOWELS (4) into the FEET (J and K). å If you're doing this to Fasten the LEFT END (B) to the TOP (C), BOTTOM (D), and å help a friend, don't SHELVES (E, F, and G). Tighten ten HIDDEN CAMS. leave without a bite.
  • Page 12 Step 8 Insert two SMALL WOOD DOWELS (4) into the FEET (J and K). å Fasten the RIGHT END (A) to the TOP (C), BOTTOM (D), and å SHELVES (E, F, and G). Tighten ten HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the TOP, BOTTOM, å...
  • Page 13 Step 9 Carefully turn your unit over onto its front edges. Unfold å Caution the BACK (O) and lay it over your unit. Do not stand the unit upright without the Make equal margins along all four edges of the BACK (O). å...
  • Page 14 Step 10 Carefully stand your unit upright. Place your unit in its fi nal å location against a wall. Pro Tip: Lift with your legs. And, you know, We recommend using the FURNITURE TIPPING å your arms. RESTRAINT KIT (99) for added stability. Fasten a bracket to the TOP (C) using the 5/8"...
  • Page 15 Step 11 Push the RUBBER SLEEVES (9) over the METAL PINS (8). å Insert the METAL PINS into the hole locations of your choice in the ENDS (A and B). Set the ADJUSTABLE SHELF (H) onto the METAL PINS. Peel a sticker from the APPLIQUE CARD (10) and place onto å...
  • Page 16 Step 12 Fasten the GUIDES (5 and 6) to the DOORS (M and N) exactly å as shown. Use sixteen BLACK 1/2" FLAT HEAD SCREWS (14). Fasten the DOOR HANDLES (7) to the DOORS (M and N). Use å eight BLACK 1/2" PAN HEAD SCREWS (13). BLACK 1/2"...
  • Page 17 Step 13 NOTE: The UPPER GUIDE (5) tabs should be down before starting this step. å Insert the LOWER GUIDES (6) in the LEFT DOOR (M) at an angle into the rear å track in the BOTTOM (D). Then, tilt the LEFT DOOR (M) up vertically. Push the UPPER GUIDE (5) tabs up into the rear track in the LOWER SHELF (G).
  • Page 18 Step 14 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å no load 15 lbs. 25 lbs. 25 lbs. 20 lbs.
  • Page 19 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
