- Page 1 Teknik www.teknikoffice.co.uk The stories of your life. Narrow Bookcase Hampstead Park Collection | Model 5420283 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-23 Hammer Not actual size Français 24-27 Español 28-31 Skip the power trip. Safety 32-34 This time. Warranty Page 2...
- Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. RIGHT END (1) LEFT FRONT/RIGHT REAR FOOT (2) LEFT END (1)
- Page 4 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. (EXTENSION SET SHOWN SEPARATED) EXTENSION RAIL - 4 EXTENSION SLIDE - 4 LARGE HIDDEN CAM- 36 SMALL HIDDEN CAM - 12 ANGLED HEAD STRAIGHT HEAD LONG WOOD SHORT WOOD...
- Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Fasten the TOP MOLDING (C) to the TOP (D). Use three å BLACK 1-1/8" FLAT HEAD SCREWS (20). Insert eight LONG WOOD DOWELS (7) into the exact å...
- Page 6 Step 2 Insert eight LONG WOOD DOWELS (7) into å the exact holes shown in the short edges of the Some assembly SHELVES (F and G). (and snacks) required. Rounded edge Rounded edge Page 6...
- Page 7 Step 3 Turn eight ANGLED CAM SCREWS (5) into the small å holes in the BOTTOM (I). Angled head Insert four LONG WOOD DOWELS (7) into the edges of å the BOTTOM (I). Finished edge Page 7...
- Page 8 Step 4 Turn two ANGLED HEAD CAM SCREWS (5) into the å FEET (J and K). Insert two LONG WOOD DOWELS (7) into the FEET (J and K) å and one into the long edge of the BOTTOM BRACE (L). Angled head Insert two LARGE HIDDEN CAMS (3) into the holes in the å...
- Page 9 Step 5 Insert four LONG WOOD DOWELS (7) into the BOTTOM (I). å Insert eight LARGE HIDDEN CAMS (3) completely into the å Angled head holes in the BOTTOM BRACE (L) and FEET (J and K) as shown. Fasten the FEET (J and K) and BOTTOM BRACES (L) to the å...
- Page 10 Step 6 Separate the EXTENSION SLIDES (2) from the EXTENSION RAILS (1) as shown in the diagram. Be å prepared; the parts are greasy. Fasten two EXTENSION RAILS (1) to the LEFT END (B). Use six BLACK 1/2" PAN HEAD SCREWS (22). å...
- Page 11 Step 7 Fasten two EXTENSION RAILS (1) to the RIGHT END (A). å Use six BLACK 1/2" PAN HEAD SCREWS (22). NOTE: For each EXTENSION RAIL, turn a SCREW into å the holes shown in the diagram. Then, slide the inner cartridge of the EXTENSION RAIL in to fi...
- Page 12 Step 8 Insert two SHORT WOOD DOWELS (8) into the FEET (J and K). å Insert twelve LARGE HIDDEN CAMS (3) into the TOP (D), SHELVES (E , F and G), BRACE (H) and BOTTOM (I). å Fasten the LEFT END (B) to the TOP (D), SHELVES (E , F and G), BRACE (H) and BOTTOM (I). Tighten twelve LARGE å...
- Page 13 Step 9 Insert two SHORT WOOD DOWELS (8) into the FEET (J and K). å Insert twelve LARGE HIDDEN CAMS (3) into the TOP (D), SHELVES (E , F å and G), BRACE (H) and BOTTOM (I). Fasten the RIGHT END (A) to the TOP (D), SHELVES (E , F and G), BRACE (H), å...
- Page 14 Step 10 Carefully turn your unit over onto its front edges. Unfold the å BACK (S) and lay it over your unit. Now might be a good time to refresh Place packing material under the angled ends to stabilize the unit. å...
- Page 15 Step 11 Fasten two EXTENSION SLIDES (2) to the DRAWER å SIDES (M and O). Use six BLACK 1/2" PAN HEAD SCREWS (22) through holes 3, 6, and 9 from the open end. NOTE: Complete steps 11-17 for assembly of one drawer. å...
- Page 16 Step 12 Turn six STRAIGHT HEAD CAM SCREWS (6) into the å DRAWER FRONT (R). Fasten a KNOB (10) to the DRAWER FRONT (R). Use a BLACK å 7/8" MACHINE SCREW (21). Fasten a FRONT FILE GLIDE (13) to the DRAWER FRONT (R) as å...
- Page 17 Step 13 Rotate the DRAWER FRONT (R) and position it as shown. å Insert six SMALL HIDDEN CAMS (4) into one DRAWER å SIDE (M and O) and a DRAWER BRACE (Q). Fasten the DRAWER SIDES (M and O) and DRAWER å...
- Page 18 Step 14 Slide a DRAWER BOTTOM (P) into the grooves in the å DRAWER SIDES (M and O) and DRAWER FRONT (R). Unfi nished surface Page 18...
- Page 19 Step 15 Fasten a DRAWER BACK (N) to the DRAWER SIDES (M å and O) and DRAWER BRACE (Q). Use six BLACK 1-1/2" FLAT HEAD SCREWS (19). Unfi nished surface BLACK 1-1/2" FLAT HEAD SCREW (6 used in this step) Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove.
- Page 20 Step 16 Push two SHORT FILE GLIDES (12) onto the DRAWER å SIDES (M and O) as shown. Push a LONG FILE GLIDE (11) onto the DRAWER BACK (N) å as shown. Page 20...
- Page 21 Step 17 Push two FILE HANGERS (14) onto the FRONT FILE å GLIDE (13) and LONG FILE GLIDE (11). Almost time to Repeat steps 11-17. celebrate! With a nap. å Page 21...
- Page 22 Step 18 Carefully stand your unit upright. å Before inserting the drawers, move your unit close to its fi nal position. å To insert the drawers into your unit, line up the EXTENSION SLIDES on the drawers with the EXTENSION RAILS on the å...
- Page 23 Step 19 We recommend using the FURNITURE TIPPING RESTRAINT KIT (99) for added stability. å Fasten a bracket to the back edge of the TOP (D) using the 5/8" screws as shown. NOTE: You will use the hole in the BACK that were not used in Step 10. å...
- Page 24 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
