Assembly Instructions
ASSEMBLY INSTRUCTIONS
7
8
Attach panels [8] and [9] to panel [2] and secure with 8 x long screws (D).
Tighten with a screwdriver. Attach 4 x plastic guides (K) to panel [8] with
a hammer.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558 mocka.co.nz | mocka.com.au
9
9
8
8
Slide panel [16] between the grooves on panels [3] and [4] to form the
back of the unit as shown.
5
5
5
