VCU110 Hardware Setup
Connect a USB Type-A to Micro-B
cable to the USB UART connector
(J4) on the VCU110 board
Connect a USB Type-A to Micro-B
cable to the USB JTAG (Digilent)
(J135) connector on the VCU110
board
Connect the Ethernet cable to P3
Connect these cables to your PC
Note: Presentation applies to the VCU110
