Optional ExaMax/Interlaken Hardware Setup
If needed, adjust the metal
supports and corresponding
backplane spikes to the wide
positions
For the FCI Backplane, use
the slots marked "OIF
Compliant"
For the Samtec Backplane,
use slots J5 and J10
Very carefully insert the two
VCU110 boards into the
backplane
Carefully attach the Interlaken
cable to the two VCU110
boards
Note: Presentation applies to the VCU110
