Summary of Contents for CoolGear USBG-7U3ML

  • Page 1 USB 3.0 7-Port Industrial Hub Metal Case with Din- Rail Mount Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USBG-7U3ML www.coolgear.com...
  • Page 2 Coolgear New Manual Format About this document This product manual outlines installation and features of the USBG-7U3ML USB 3.0 7- Port Industrial Hub Metal Case with Din-Rail Mount. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
  • Page 3: Table Of Contents

    USBG-7U3ML – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Hardware Installation ..................... 6 Checking the Hub Installation ................. 6 Environmental Specifications ................. 7 2. Notes, Tips, Warnings, and Safety ................. 8 3.
  • Page 4: Introduction

    USBG-7U3ML – Product Manual 1. Introduction The USBG-7U3ML is a USB 3.0 Hub that complies with Universal Serial Bus 3.0 (USB 3.0) Specifications Revision 1.0 and works with up to 5Gbps. It provides 7 downstream facing ports with standard Type-A USB 3.0 connectors.
  • Page 5: Connector Layout

    USBG-7U3ML – Product Manual 1.2 Connector Layout Figure 1 USB 3.0 Upstream Port USB 3.0 Downstream Port Self Power Input Type-B connector from There are 7 Type-A This 2-pin (one pin for upstream USB 3.0 port. It is connectors for USB 3.0,...
  • Page 6: Hardware Installation

    USBG-7U3ML – Product Manual 1.3 Hardware Installation 1. Use static electricity discharge precautions. Remove possible static discharge potential from any objects that the hub may come in contact with before installation. This can be accomplished by touching a bare metal chassis rail after you have turned off the power.
  • Page 7: Environmental Specifications

    USBG-7U3ML – Product Manual 1.5 Environmental Specifications Specification Data Operating Temperature: 0-55°C (32 to 131°F) Operating Humidity: 5 to 95% RH www.coolgear.com...
  • Page 8: Notes, Tips, Warnings, And Safety

    USBG-7U3ML – Product Manual 2. Notes, Tips, Warnings, and Safety Note Please make sure the polarity of the input power should be correctly matched with the terminal block pins to function properly. Warning Figure 4 • Read the entire Product Manual before implementing this product for your application.
  • Page 9: Supporting References

    © 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
