- Page 1 USB 3.1 4 Port Metal Hub w/DIN Rail Clip & ESD Surge Protection Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USBG-4U3MLR2 www.coolgear.com...
- Page 2 Coolgear New Manual About this document This product manual outlines installation and features of the USBG-4U3MLR2 USB 3.1 4 Port Metal Hub w/DIN Rail Clip & ESD Surge Protection. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
USBG-4U3MLR2 – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Hardware Installation ..................... 6 Checking the Hub Installation ................. 7 Environmental Specifications ................. 7 2. Notes, Tips, Warnings, & Safety ................8 3. -
Page 4: Introduction
5Gbps data transmission. It supports 7-48V through its 2-wire plug connector for extra power to hungry devices (power adapter sold separately). The new, redesigned Coolgear USB 3.1 Gen1 hub has the same great performance and is the best buy for your money in its series. -
Page 5: Connector Layout
USBG-4U3MLR2 – Product Manual 1.2 Connector Layout Figure 1 USB 3.1 Upstream Port USB 3.0 Downstream Port Self Power Input Type-B female connector There are 4 Type-A female This 2-pin (one pin for from upstream USB 3.1 connectors for USB 3.1, positive voltage and the port. -
Page 6: Hardware Installation
USBG-4U3MLR2 – Product Manual 1.3 Hardware Installation 1. Use static electricity discharge precautions. Remove possible static discharge potential from any objects that the hub may come in contact with before installation. This can be accomplished by touching a bare metal chassis rail after you have turned off the power. -
Page 7: Checking The Hub Installation
USBG-4U3MLR2 – Product Manual 1.4 Checking the Hub Installation To check the USB hub installation in Windows device manager, please follow the following steps: 1. Click Start 2. Click Control Panel 3. Click System 4. Click Device Manager button 5. Double Click Universal Serial Bus Controller 6. -
Page 8: Notes, Tips, Warnings, & Safety
USBG-4U3MLR2 – Product Manual 2. Notes, Tips, Warnings, & Safety In some cases, you will see an error message said that the USB Hub caused the USB bus power over current limit, please ignore this message since the Note hub is hot plug and its power capacitor will cause a very short period of current. -
Page 9: Supporting References
© 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
