7-Port USB 2.0 Hub with Metal Case – Installation Guide
1. Introduction: USBG-7U2ML
The High-Speed 7-port USB 2.0 hub provides an ideal solution to expand 7 USB 2.0 ports from one single USB 2.0 host
port. It provides 2 optional self power sources (from DC jack or small 4-pin power connector) to provide enough power
on USB 2 .0 buses.
FEATURES:
•
Compliant with USB Specification Revision 2.0
•
Rigid and Wall-mountable Metal Case
•
Supports High-speed and or Full-speed Packet
•
Protocol Sequencer for Endpoint 0/1
•
Provides 7 Downstream Facing Ports
•
Supports 480Mbps, 12Mbps and 1.5Mbps Speed
•
Supports Self-powered and Bus-powered Mode
2. Connector Layout
Power LED
Port #1
USB 2.0 Connector
+5V DC Jack
(upstream port)
Downstream USB 2.0 Ports
Type-B USB 2.0
Small 4-pin Aux
Upstream
power Connector
Connector
Sales@coolgear.com
Small 4-pin Aux
power Connector
Port #7
+5V DC Jack
(AC Adapter)
