- Page 1 Metal 4-Port USB 2.0 Powered Hub for Industrial Use w/Screw Lock Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USBG-4SU2MLA www.coolgear.com...
- Page 2 Coolgear New Manual Format About this document This product manual outlines installation and features of the USBG-4SU2MLA Metal 4- Port USB 2.0 Powered Hub for Industrial Use w/ Screw Lock. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
Checking the Hub Installation ................. 6 Environmental Specifications ................. 7 2. Notes, Tips, Warnings, and Safety ................. 8 3. Supporting References ..................9 Table of Figures Figure 1 – Back Panel Connections………………………………………………………………….……………..5 Figure 2 – Front Panel Connections……..…………………………………………………………………………5 Figure 3 - Device Manager Screen..................6 www.coolgear.com... -
Page 4: Introduction
USBG-4U2ML – Product Manual 1. Introduction The USBG-4SU2MLA is an Industrial-grade metal 4-Port USB 2.0 Powered Hub that allows you to secure your devices by the connection of a screw lock port. Never come unplugged during synchronization again! The USB 2.0 controller works backward compatible either when any one of downstream port is connected to an USB 1.1... -
Page 5: Front And Back Connections
Lock or Screw-Lock connected to here. or Screw-Lock type cables. (optional) cables. 1.2 Front and Back Connections Back Side Connection Figure 1 Front Side Connection Figure 2 www.coolgear.com... -
Page 6: Hardware Installation
1. Click Start 2. Click Control Panel 3. Click System 4. Click Device Manager button 5. Double Click Universal Serial Bus Controller 6. Double click Generic USB Hub, the message will show that this device is Figure 3 working properly www.coolgear.com... -
Page 7: Environmental Specifications
USBG-4U2ML – Product Manual 1.5 Environmental Specifications Specification Data Operating Temperature: 0-55°C (32 to 131°F) Operating Humidity: 5 to 95% RH www.coolgear.com... -
Page 8: Notes, Tips, Warnings, And Safety
• Do not disassemble the product. Handling the product’s internal components can expose it to ESD (Electro-Static Discharge) hazards that can affect the function of the device. • If this product is not functioning properly, email our support team at support@coolgear.com. www.coolgear.com... -
Page 9: Supporting References
USBG-4U2ML – Product Manual 3. Supporting References Document Link Website Product Page https://www.coolgear.com/product/metal-4- port-usb-2-0-powered-hub-industrial-use-w- screw-lock www.coolgear.com...
