- Page 1 Metal 7-Port USB 2.0 Hub – Din RAIL Mounting Japan NEC Chip Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USBG-7DU2 www.coolgear.com...
- Page 2 Coolgear New Manual Format About this document This product manual outlines installation and features of the USBG-7DU2 Metal 7-Port USB 2.0 Hub – DIN RAIL Mounting Japan NEC Chip. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
USBG-7DU2 – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Hardware Installation ..................... 5 Checking the Hub Installation ................. 6 Environmental Specifications ................. 6 Drawing ........................6 2. Notes, Tips, Warnings, and Safety ................. 8 3. -
Page 4: Introduction
USBG-7DU2 – Product Manual 1. Introduction The USBG-7DU2 7-Port USB 2.0 Hub provides unique features to work in the bus- powered mode without an external AC power adapter, it also features an external 2-pin Terminal Block Connector for self-powered mode. The High-Speed 7-port USB 2.0 hub provides an ideal solution to expand 7 USB 2.0 ports from one single USB 2.0 host port. -
Page 5: Connector Layout
USBG-7DU2 – Product Manual 1.2 Connector Layout Figure 1 Upstream Port Connector Self Power Input Connector Type-B connector from upstream USB 2.0 This 2-pin (one pin plus voltage and the port. It is connected from host or another other pin is ground) terminal block USB 2.0 hub. -
Page 6: Checking The Hub Installation
USBG-7DU2 – Product Manual 1.4 Checking the Hub Installation To check the USB hub installation in Windows device manager, please follow the following steps: 1. Click Start 2. Click Control Panel 3. Click System 4. Click Device Manager button 5. Double Click Universal Serial Bus Controller 6. -
Page 7: Figure 4 - Dimensional Drawing
USBG-7DU2 – Product Manual Figure 4 www.coolgear.com... -
Page 8: Notes, Tips, Warnings, And Safety
USBG-7DU2 – Product Manual 2. Notes, Tips, Warnings, and Safety In some cases, you will see an error message said that the USB Hub caused the USB bus power over the current limit, please ignore this message since Note the hub is hot plug and its power capacitor will cause a very short period of current. -
Page 9: Supporting References
