- Page 1 USB 3.0 4-Port Industrial Hub with Power Supply Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: USBG-3X4M www.coolgear.com...
- Page 2 USBG-3X4M – Product Manual Revision History Revision Date Author Comments 07/14/2015 Coolgear Original format 09/28/2017 Coolgear New Manual Format About this document This product manual outlines installation and features of the USBG-3X4M USB 3.0 industrial 4 port hub. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
Circuit Image ......................7 2. Notes, Tips, Warnings, and Safety ................. 8 3. Supporting References ..................9 Table of Figures Figure 1 – Connector Layout…………………………………………………………………………………………..5 Figure 2 – Screw Lock Connection………..…………………………………………………………………………6 Figure 3 - Device Manager....................6 Figure 4 – Circuit Image……………………………………………………………………………………………….…7 www.coolgear.com... -
Page 4: Introduction
USBG-3X4M – Product Manual 1. Introduction The USBG3-3X4M is a 4 Port USB 3.0 Hub that complies with the Universal Serial Bus 3.0 (USB 3.0) Specifications Revision 1.0 and works up to 5Gbps. The design incorporates dual power conversion systems to operate to USB 3.0 maximum current for each port. -
Page 5: Hardware Installation
Please connect the type-A end connector of the cable to your upstream USB port, then connect the type-B end connector to this hub. Since the USB hub is plug-and-play, you don’t have to turn off your host computer when installing the hub. www.coolgear.com... -
Page 6: Checking The Hub Installation
5. Double Click Universal Serial Bus Controller 6. Double click Generic USB Hub, the message will show that this device is working properly Figure 3 1.5 Environmental Specifications Specification Data Operating Temperature: 0-55°C (32 to 131°F) Operating Humidity: 5 to 95% RH www.coolgear.com... -
Page 7: Circuit Image
USBG-3X4M – Product Manual 1.6 Circuit Image Figure 4 www.coolgear.com... -
Page 8: Notes, Tips, Warnings, And Safety
• Do not disassemble the product. Handling the product’s internal components can expose it to ESD (Electro-Static Discharge) hazards that can affect the function of the device. • If this product is not functioning properly, email our support team at support@coolgear.com. www.coolgear.com... -
Page 9: Supporting References
© 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
