- Page 1 Unpacking Please make sure the package contains the following items: ST4X20 screw x 2 M4X30 screw x 2 Screw fixing seat x 2 10 Pin cable x 1 11 Pin cable x 1 Wall bracket x 1 C313X x 1...
-
Page 2: Product Overview
C313X Product Overview Front Panel Touch Screen C313X... -
Page 3: Rear Panel
C313X Rear Panel Loudspeaker Network Interface（Power in） RJ45 Interface 10 Pin Terminals 11 Pin Terminals... -
Page 4: Installation
C313X Installation Without 86 embedded box in the wall Take down the bracket, Mark two fixation holes through then using a 5mm hand drill wall bracket on the wall,the to make the two fixation distance between which is holes on the wall you 60mm. -
Page 5: Device Mounting
C313X With 86 embedded box in the wall Fix the wall bracket on the Make sure all cables in 86 embedded box with the 86 embedded box. two M4X30 screws. Device Mounting Push down to fix the device securely. -
Page 6: Operation
C313X Configuration 1. After setting up network and power, press Status icon to check IP address (DHCP by default). 2. Launch web browser and type in the IP address to access web interface, login with username and password.(admin by default). - Page 7 C313X Unlock During the talk, press the Open Door key in talking interface to unlock the door. Monitor Press Monitor key to receive the video from indoor IPC or community IPC any time. Press SOS key in case of an emergency.
