Description:
TS93 STH
PULL SIDE TRACK MOUNT
1
(REFERENCE UNIT CARTON LABEL FOR ACCESSORIES AND OPTIONS SUPPLIED)
Determine hand of door and degree of deadstop required.
Prepare door and frame for fasteners
2
Attach mounting plate to frame using lower four
holes in plate. Arrows on plate point up.
RIGHT HAND DOOR
3
Attach closer to mounting plate.
RIGHT HAND DOOR
4
Attach arm to pinion of closer, parallel to door.
M5 HEX KEY
www.dorma-usa.com
according to template 08280612.
QTY
(4)
QTY
(1)
RIGHT HAND DOOR
1-800-523-8483
LEFT HAND DOOR
QTY
METAL
(4)
FRAME
LEFT HAND DOOR
M5 HEX KEY
INSPK NO. 08280610
08280611
INS NO.
RIGHT HAND DOOR
WOOD
FRAME
LEFT HAND DOOR
LEFT HAND DOOR
Rev.08/09
1 of 3
PAGE
Rev.
08/09
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dorma TS93 Series
Summary of Contents for Dorma TS93 Series
- Page 1 RIGHT HAND DOOR LEFT HAND DOOR Attach arm to pinion of closer, parallel to door. RIGHT HAND DOOR LEFT HAND DOOR M5 HEX KEY M5 HEX KEY INSPK NO. 08280610 Rev.08/09 1 of 3 08/09 08280611 PAGE Rev. www.dorma-usa.com 1-800-523-8483 INS NO.
- Page 2 Adjust sweep, latch, backcheck and delayed Assemble track and attach to door. action valves. Insert slide shoe and end blocks into track with spring block CAUTION: DO NOT REMOVE VALVES. near the hinge side of door frame. Attach track to door using track mounting screws. LATCH RANGE DECREASE DELAY...
- Page 3 Adjust spring tension, if required. M5 HEX KEY CRITICAL CAUTION: DO NOT OVERTIGHTEN NOTE: TS93-1 supplied with a size 2 spring setting. REFERENCE LABEL ON CLOSER FOR MINIMUM/MAXIMUM SETTINGS BARRIER-FREE OPENINGS - FULL TURNS OF CLOSER Take an opening force reading from DOOR WIDTH the pull on the door.
