Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Main Advanced Chipset Security
BIOS Information
BIOS Vendor American Megatrends
NDiS-S538
Product Name
BIOS Version D538-005 x64
Build Date and Time 03/25/2019 11:55:20
Processor Information
Name Skylake DT
Type Intel(R) Core(TM)
i5-6500TE CPU @ 2.30GHz
Speed 2300 MHz
0x506E3
ID
Stepping R0/S0/N0
Number of Processors 4Core(s) / 4Thread(s)
Microcode Revision C2
GT Info GT2 (0x1912)
IGFX GOP Version N/A
Memory RC Version 2.0.0.6
Total Memory 16384 MB
2133 MHz
Memory Frequency
PCH Information
Name SKL PCH-H
PCH SKU Q170
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
▲
Set the Date. Use Tab to
switch between Date elements.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Main Advanced Chipset
Speed
ID
Stepping
to
Number of Processors
Microcode Revision
GT Info
IGFX GOP Version
Memory RC Version
Total Memory
Memory Frequency
PCH Information
Name
PCH SKU
Stepping
TXT Capability of Platform/PCH
Production Type
ME FW Version
ME Firmware SKU
System Date
System Time
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
1999 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
33
Security Boot Save & Exit
▲
2300 MHz
Set the Time. Use Tab to
0x506E3 switch between Time elements.
R0/S0/M0
4Core(s) / 4Thread(s)
C2
GT2 (0x1912)
N/A
2.0.0.6
16384 MB
2133 MHz
SKL PCH-H
Q170
→←: Select Screen
D1
↑↓: Select Item
Supported
Enter: Select
Production
+/-: Change Opt.
F1: General Help
11.6.0.1126
F2: Previous Values
Corporate SKU
F3: Optimized Defaults
F4: Save & Exit
[Thu 06/27/2019] ESC: Exit
[16:28:11]
▼
