Extender Plus Series • Setup Guide (Continued)
Step 4
Attach and wire the cables as shown in the image below. The Extender Plus D has the same
circuit board configuration (see Rear Panel Features and Cabling in the Extender Plus Series
User Guide for more details).
NOTE: If the Extender Plus AAP is installed in an Extron HSA 400 Series or 800 Series
surface access product, install the Extender into the faceplate before attaching the
cables.
ATTENTION:
• For unbalanced audio,
connect the sleeves
to the ground contact.
DO NOT connect the
sleeves to the negative
(–) contacts.
• Pour l'audio
asymétrique, connectez
les manchons au
contact au sol. Ne PAS
connecter les manchons
aux contacts négatifs (–).
NOTE: Horizontal sync = black
Vertical sync = yellow
Step 5
Connect power and turn the equipment on.
Step 6
Test the system and set the gain switch. Ensure that all devices
receive power. Check and adjust cabling and gain as needed.
Step 7
Disconnect power from all the devices.
Step 8
Mount the line driver into the electrical box or the Plus AAP model into the body of the HSA.
For the Extender Plus D, install the decorator‑style faceplate.
Step 9
Restore power to the devices.
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron Europe
+31.33.453.4040
© 2017 Extron Electronics — All rights reserved. All trademarks mentioned are the property of their respective owners.
N D
T E
E X
U T
M P
T
C O
O U
Extron Asia
+65.6383.4400
Extron Japan
+81.3.3511.7655
C T
L E
S E
I D
E D
C
6 0
H z
O N
s D R
5 0 W E
P l u
I N E P O
2
O R
G A
A X
E R S T 1
V
1 2
A M
0 . 2
T
O U
E R
O
D I
R
A U
L
Right Ring
Right Tip
Sleeve (s)
Left Ring
Left Tip
Do not tin the wires!
Gain Switch
Extron China
+86.21.3760.1568)
Extron Middle East
+971.4.299.1800
Power
NO Ground Here
12 VDC
Right Tip
Sleeve (s)
NO Ground Here
Left Tip
Audio
Unbalanced Output
Right Ring
Right Tip
Sleeve (s)
Left Ring
Left Tip
Balanced Output
GAIN
(viewed
from front)
