Installation Instruction
Carefully open the carton, remove contents and lay out on cardboard or other
!
protective surface to avoid damage.
Check package contents against the Supplied Parts List in the next page to assure
!
that all components were received undamaged. Do not use damaged or defective
parts.
Carefully read all instructions before attempting installation.
!
IMPORTANT SAFETY INFORMATION
Install and operate this device with care. Please read this instruction before
!
installation, and carefully follow all instructions contained herein. Use proper safety
equipment during installation.
Please call a qualified installation contractor for help if you don't understand these
!
directions or have any doubts about the safety of the installation.
Do not use this product for any purpose or in any configuration not explicitly specified
in this instruction. We hereby disclaims any and all liability for injury or damage
arising from incorrect assembly, incorrect mounting, or incorrect use of this product.
UNPACKING INSTRUCTIONS
1
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mount-It! MI-792
Summary of Contents for Mount-It! MI-792
- Page 1 English Installation Instruction UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged. Do not use damaged or defective parts.
- Page 2 Supplied Par ts List (1) 35mm Pole-a (1) Weighted Base-b (1) Monitor Arm-c (1) Plastic Cover-d (1)M10 Bolt-e (1)Support Plate-f (1)M10 Washer-g (1)Spring Washer-h (8)M4x12 (2)Wire Clip-i (3)M6x29 Bolt-j (1)Allen Key-k Thumb Bolt-l (8)M4x30 Bolt-m (8)M4 Space-n (16)M4 Washer-o (1)Wrench-q (4)Cable Ring-p Tools Required Phillips Screwdriver...
- Page 3 Mounting the base according to your requirement Step 1 The stand can be used with the weighted Option 1 metal base or there is a desk attachment provided (as drawings on the bottom) allowing you to mount the stand on a desk. This is very simple to install and just requires a hole drilling (10mm diameter) in your desk and clamping with the bolt and...
- Page 4 Install Monitor Arm to the Pole Step 2 Install Monitor Arm-c to the pole. Fasten the bolt by supplied Allen Key(k). Mount the Monitor to VESA Plate Step 3 For Flat Back Monitor For Curved Back Monitor...
- Page 5 Do the Necessary Adjustment Step 4 knob Use the Allen Key(k) to adjust the Fasten the knob to fix the tilting height of monitors. angle. Install the Wire Clips & Manage the Wires Step 5 Thank you for choosing our products!
