Océ ⏐ LightJet 430
Site Preparation Guide
Revision J · June 2005
Document # 3010045572

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LightJet 430 and is the answer not in the manual?

Questions and answers

Related Manuals for Oce LightJet 430

Summary of Contents for Oce LightJet 430

  • Page 1 Océ ⏐ LightJet 430 Site Preparation Guide Revision J · June 2005 Document # 3010045572...
  • Page 2 Océ Display Graphics Systems © 2002 ALL RIGHTS RESERVED...

  • Page 3: Table Of Contents

    Table of Contents Copyright and Document History ..............iii Product Support, Documentation and Service..........iii Product Compliance and Standards..............v Introduction ................1-1 Using This Guide..................1-1 Important Safety Information For All Users ..........1-1 System Requirements ............2-1 ® Receiving and Moving the LightJet 430............2-1 Receiving the Shipping Crate..............2-1 Hallway Requirements................2-2...
  • Page 4 LightJet 430 site preparation guide List of Figures ® Figure 2-1 LightJet 430 shipping crate dimensions..........2-2 ® Figure 2-2 LightJet 430 dimensions............... 2-3 Figure 2-3 Building access requirements..............2-4 Figure 2-4 Darkroom size requirements..............2-5 Figure 2-5 Left side connections.

  • Page 5: Product Support, Documentation And Service

    Océ Display Graphics Systems, please contact: Océ Display Graphics Systems 13231 Delf Place, #501 Richmond, British Columbia, Canada V6V 2C3 Phone: (604) 273-7730 Fax: (604) 273-2775 Web: http://www.dgs.oce.com FTP Site: http://www.cymbolic.com/ftp.html Comments on this guide? Please feel free to contact us at: Technical.Writer@dgs.oceusa.com ®...
  • Page 6 LightJet 430 site preparation guide For technical support call your local Océ service centre. If we are unable to resolve your problem over the telephone, field engineers can be dispatched to your site to conduct repairs. Service visits are paid for by the customer, either under a maintenance agreement or by purchase order or prepayment.

  • Page 7: Product Compliance And Standards

    Copyright, Product Support, Product Compliance and Standards Product Compliance and Standards Electromagnetic Compatibility This equipment generates, uses and radiates radio frequency energy and if not installed and used as designed or intended, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class A computing device.
  • Page 8 LightJet 430 site preparation guide Laser Safety This equipment is a Class 1 laser product which is safe under all operating conditions. The following standards were used to evaluate compliance: United States of America Center for Devices and Radiological Health (CDRH)

  • Page 9: Introduction

    Introduction Introduction This manual is applicable to both the LightJet 430 and LightJet 430RS printers. All references to the LightJet 430 also refer to the LightJet 430RS. The LightJet® 430 is a wide format digital color printer capable of producing large photographic quality images on various paper and film materials from several data formats.
  • Page 10 LightJet 430 site preparation guide CAUTION DANGER: LASER RADIATION: THIS EQUIPMENT WILL EMIT LASER RADIATION WHEN OPEN AND INTERLOCK SWITCHES DEFEATED. AVOID EYE EXPOSURE TO DIRECT AND SCATTERED LASER RADIATION. DANGER: RADIATIONS LASER: CET ÉQUIPEMENT PEUT ÉMETTRE DES RADIATIONS LASER LORSQU’IL...

  • Page 11: System Requirements

    System Requirements System Requirements NOTE The LightJet® 430 is a digital photo printer intended for operation under conditions of a controlled environment. Photo printers are classified as information technology equipment (ITE), and are subject to applicable ITE test and working environment standards.

  • Page 12: Hallway Requirements

    LightJet 430 site preparation guide Shock Watch ® Figure 2-1 LightJet 430 shipping crate dimensions. Hallway Requirements ® Once uncrated, the LightJet 430 can be rolled on its own casters. The printer weighs approximately 818 kg (1800 lb). To prevent collisions and/or damage, it is recommended that at least two people move it.

  • Page 13: Figure 2-2 Lightjet 430 Dimensions

    System Requirements ® Figure 2-2 LightJet 430 dimensions. 45572-I see copyright, disclosure, use and duplication information on pg. iii...

  • Page 14: Darkroom Requirements

    LightJet 430 site preparation guide 213 cm (7’) Figure 2-3 Building access requirements. Darkroom Requirements ® The LightJet 430 must be installed in a darkroom environment to allow for loading and unloading of photographic media. With the covers closed, the printer can operate under lighting conditions found in a normal working environment.

  • Page 15: Electrical Requirements

    91 cm 91 cm (36”) (36”) AC Power Connector Air Hose Blower Hose Host 600 cm LightJet 430 Computer (236”) SCSI Connector Shaded Area Reserved for Operations and Maintenance (must be kept clear of obstructions) 183 cm (72”) Minimum Doorway Dimension Figure 2-4 Darkroom size requirements.

  • Page 16: Power Factor Correction

    LightJet 430 site preparation guide IMPORTANT Unplugging the power cord from the wall socket is the only way to isolate the entire machine. CAUTION CAUTION: THE SOCKET OUTLET MUST BE INSTALLED NEAR THE EQUIPMENT AND BE EASILY ACCESSIBLE. ATTENTION: LE SOCLE DE PRISE DE COURANT DOIT ÊTRE INSTALLÉ A PROXIMITÉ...

  • Page 17: Power Cord Specifications

    System Requirements Separate, full-size insulated power and ground wires are required on all dedicated circuits. No chained grounds are permitted. Use of the conduit as the equipment grounding conductor is not permitted on isolated ground receptacles. Power Cord Specifications The appropriate cord set is supplied with each machine. For replacement cord sets, contact the following suppliers: North America Manufacturer...

  • Page 18: Environmental Requirements

    LightJet 430 site preparation guide Environmental Requirements Heat Removal ® The LightJet 430 can produce up to 8200 BTU per hour (2380 watts) and must have adequate heat removal. Ensure the darkroom is equipped as follows: A dedicated 3” (76mm) unrestricted air duct and flexible hose (max. length-15’ or 4.6 m) directing the heated air out of the darkroom.

  • Page 19: House Air

    System Requirements House Air ® It is the customer’s responsibility to provide compressed air to the LightJet 430. As shown in Figure 2-6, a 6.35 mm (1/4”) hose (no fittings required) is required to deliver compressed air to the printer. 6.35 mm (1/4") hose Figure 2-6 Right side connections.

  • Page 20: Environmental Operating Specifications

    LightJet 430 site preparation guide Environmental Operating Specifications Temperature: 19ºC to 28ºC (66ºF to 82ºF) within a 5ºC band Relative humidity: 40% to 60% Altitude: 0 to 2 286 meters (0 to 7 500 feet ) Shipping and Storage ®...

  • Page 21: Customer Equipment Requirements

    System Requirements specified limits have been exceeded. Tamper-proof seals are also added to ensure the crate has not been opened and the contents interfered with. Customer Equipment Requirements Densitometer ® A color transmission/reflective densitometer is used in the calibration of the LightJet 430;...
  • Page 22 PosterShop Server LightJet Spooler Control Input: Output : Network/Local: PosterShop Clients From local disk to LightJet 430 via & Hotfolders, Removable media. Adaptec 19160 SCSI card Output : V ia network to database on LightJet Spooler computer...
  • Page 23 System Requirements ® LightJet FE Host Requirements Selection of the host platform will have an impact on production throughput. The following are ® the LightJet 430 host computer’s minimum hardware and software requirements for printing with PosterShop. For the most recent hardware and software recommendations, consult the support pages of our web site at http://www.cymbolic.com/ftp.html.

  • Page 24: Operator Training

    LightJet 430 site preparation guide Onyx PosterShop® Pro Server Requirements ® Onyx PosterShop software is the imposition software used to generate the image files that are ® ® queued to LightJet FE for printing on the LightJet 430. For the most recent hardware and software recommendations go to the Onyx web site: http://www.onyxgfx.com/solutions_postershop.html...

  • Page 25: Supported Media Specifications

    System Requirements Supported Media Specifications ® The LightJet 430 can image on the following media types and sizes: Supported RA4 Media Types Paper Trans Flex Supported Length 50 m (164’) 30.5 m (100’) 30.5 m (100’) (maximum): Supported Widths for All Three Media Types 76 cm (30”) 81 cm (32”) 102 cm (40”)
  • Page 26 LightJet 430 site preparation guide THIS PAGE INTENTIONALLY LEFT BLANK 2-16 see copyright, disclosure, use and duplication information on pg. iii 45572-I...

  • Page 27: Appendix A: Pre-Installation Checklist

    Pre-Installation Checklist Appendix A: Pre-Installation Checklist ® The purpose of this checklist is to help you prepare your site to accommodate the LightJet imaging system. If you have any questions regarding the contents of this checklist or how your site should be prepared, contact Océ (see “Product Support, Documentation and Service” on page iii) or your regional distributor.
  • Page 28 Customer Information Company: Date: Contact: Distributor: Address: Contact: Phone: System Requirements Checklist Requirement Space and Location Requirements: Page 2-1 Building Access with Loading Dock Loading Dock adequate to uncrate at customer facility Fork Lift available (~2500lb / 1200kg. Capability) Clear path from loading dock to darkroom Darkroom dimensions: 403 cm (158.5)”...
  • Page 29 Pre-Installation Checklist Requirement Darkroom Shock and Vibration Darkroom Heat Removal Air conditioning available (can remove 8530 BTU/hr.) Dedicated air duct (76mm/3”) House Air with 6.35 mm (1/4”) hose Customer Equipment Requirements: Page 2-11 Qualified media on hand (minimum 2 rolls of same emulsion each) Type: __________________________________ Type: __________________________________ Processor Monitored and Graphed (one per processor setup)
  • Page 30 Application Information Information Product Software Host Platform Name Version RIP Software Primary Page Layout Software (Vector) Primary Image Editing Software (Raster) Data Transport Method (e.g. Network 100baseT or Jaz) Type: ___________________ Type: ___________________ Type: ___________________ Other digital output devices: Film Recorder Inkjet E-Stat printer (e.g.
  • Page 31 Pre-Installation Checklist Installation Start Date: The customer agrees to have an operator available for the installation. This will allow the customer to get into production as quickly as possible. Signature of Océ Representative Signature of Customer Print Name Print Name End of Section A-A-5 45572-I...
  • Page 32 THIS PAGE INTENTIONALLY LEFT BLANK A-A-6 see copyright, disclosure, use and duplication information on pg. iii 45572-I...
