Oce Arizona T220UV User Manual

Hide thumbs Also See for Arizona T220UV:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Arizona T220UV
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Oce Arizona T220UV

Summary of Contents for Oce Arizona T220UV

  • Page 1 Arizona T220UV User Guide...
  • Page 2 Océ-Technologies B.V. Copyright © 2004, Océ-Technologies B.V. Venlo, The Netherlands All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ. Océ-Technologies B.V. makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.

  • Page 3: Table Of Contents

    User Interface Operator Control Panel 32 Menu Structure 36 Chapter 5 How to Operate the Arizona T220UV Training Requirements 42 How to Switch the Printer On 43 How to Set Up a Print Job 46 Select a Print Job 46...
  • Page 4 How to Install Special Prints 106 How to Print the Menu Tree 107 How to Print the Table Grid 108 Appendix B Safety Systems and Machine Safeguarding 109 Arizona T220UV Safety Systems 110 Interlock System Test Procedure 112 T220UV User Guide...

  • Page 5: Introduction

    Arizona T220UV User Guide Chapter 1 Introduction...

  • Page 6: Preface

    Preface Summary This User Guide introduces you to the Océ Arizona T220UV flatbed inkjet printer. It will orient you to the many features and procedures that enable you to print quality images on various media. Copyright  2004 Océ Display Graphics Systems. All rights reserved.
  • Page 7 A few minutes spent cleaning ensures the highest quality prints. Several areas require maintenance to ensure the highest print quality, and the printer design gives you easy access to all these areas. Refer to the Arizona T220UV User Guide for details.

  • Page 8: Product Compliance

    Operation of this equipment in a residential area may cause interference, in which case the user, at his own expense, is required to take whatever measures are required to correct the interference. The Arizona T220UV complies to the following Agencies and Standards: [1] Compliance Specifications Specification Directive...
  • Page 9 Manufacturer: Oce Display Graphics Systems (ODGS) 13231 Delf Place - Building #501 Richmond, British Columbia Canada V6V 2C3 Contact: Colin Soutar Email: colin.soutar@dgs.oceusa.com http://www.oceusa.com/ http://www.dgs.oce.com/ ( Direct Dial (604) 232-2345 Fax (604) 273-2775 Alternate Manufacturer: Océ Display Graphics Systems (ODGS)
  • Page 10 T220UV User Guide...

  • Page 11: Product Overview

    Arizona T220UV User Guide Chapter 2 Product Overview...

  • Page 12: General Description

    The gantry contains a carriage that sweeps across the table as the gantry moves in steps along the length of the table to print an image on the media. The Arizona T220UV must be operated in accordance with certain environmental and safety requirements noted in this document.

  • Page 13: Product Features

    Introduction The Arizona T220UV prints directly onto rigid media using an original flatbed technology. The printer holds the media stationary on the table while printing is in progress. In addition to the benefits of stationary positioning, the use of UV ink technology on rigid material eliminates finishing processes such as mounting and lamination.
  • Page 14 Printer Electrical Configuration The T220UV printer operates in the following two configurations: Delta (USA) Configuration: Voltage: 230VAC +/-10%, 3 Phase Frequency: 50 or 60 Hz Current: 25AMPS maximum steady state Power: 15kW max. Circuit Breaker 30 Amps Wye (European) Configuration: Voltage: 400VAC +/-10%, 3 Phase Frequency: 50 or 60 Hz Current: 25AMPS maximum steady state...

  • Page 15: Safety Information

    Arizona T220UV User Guide Chapter 3 Safety Information...

  • Page 16: Safety Guidelines

    Safety glasses with side shields when handling inks. Personal Safety The Arizona T220UV printer has an integrated safety interlock system that stops all machine motion when a situation that might compromise operator safety occurs. Thus, opening any of the gantry doors (except during authorized procedures), tripping the hinged gate on the gantry cover, or activating an Emergency-Stop button will switch the Safety Monitoring Relay input circuits.
  • Page 17 Long-Term Health Effects [3] Long-Term (Chronic) Health Effects Exposure by: Effect Inhalation: Upon prolonged and/or repeated exposure, can cause severe respiratory irritation, dizziness, weakness, fatigue, nausea, headache and possible unconsciousness. Skin Contact: Upon prolonged or repeated contact can cause severe irritation, defatting, and dermatitis. May cause lin- gering affects but not likely to result in permanent damage if the exposure is eliminated.
  • Page 18 Handling and Storage [6] Handling & Storage Handling Toxic or severely irritating material. Avoid contacting and avoid breathing the material. Use only in a Precautions: well ventilated area. As with all chemicals, good industrial hygiene practices should be followed when handling this material.

  • Page 19: Uv Lamp Safety

    Malpighian layer. Extreme caution must be taken since high power UV radiation can cause severe burns to the skin. The Arizona T220UV printer has a built-in interlock safety system that shuts down the UV lights if the gantry doors are Note: opened.

  • Page 20: Arizona T220Uv Safety Labels

    Arizona T220UV Safety Labels Introduction The safety labels are placed at strategic locations on the printer to warn the operator of possible dangers and hazards. It is important to be aware of the meaning of these labels to ensure safe operation of the printer.
  • Page 21 Safety Labels [10] Safety Labels Description Label Warning: UV Light Hazard. Avoid looking directly at light. # 3012002359 Located on gantry door to remind operator that looking at the UV light source is dangerous. Lifting Hazard, Heavy Object - #3012002361 Located on the ballast platform to remind service technicians that the ballast is heavy and to use due care if any lifting is re- quired.
  • Page 22 Description Label Before connecting Power Supply Cord to the unit, refer to the installation instruction to determine proper Input Volt- age Configuration WARNING - # 3010100315 HIGH LEAKAGE CURRENT EARTH CONNECTION ESSENTIAL BEFORE CON- NECTING SUPPLY. Located above the AC power cable Pinch Point - # 3010100726 Located on the bracket endplate and the plate end cap.

  • Page 23: Safety Awareness

    The second set of principles illustrates some of the residual risks that are inherent in the operation of the Arizona T220UV printer. These are situations or physical aspects of the printer that may present a potential danger to the operator, but would compromise the capabilities of the printer if changed.
  • Page 24 Situations to Avoid Avoid the actions and situations presented in the following table. [11] How NOT to use the Arizona T220UV Avoid these Situations For Your Personal Safety Do not place your hand under the gantry when the printer is powered on. Do not leave any objects on the table printing surface, except for media that you will print on.
  • Page 25 [11] How NOT to use the Arizona T220UV Residual Safety Risks The Arizona T220UV is engineered to minimize machine components and operating procedures that may compromise operator safety. However, in order to maintain some machine operations and functionality, certain compromises are required.
  • Page 26 Caution: there may be a time lag between when a print job is issued and when the gantry movement actually begins. [12] T220UV Residual Risks Risk Area Crushing/Shear Hazard A crushing/pinch hazard is created by the gantry and the home and away position tabs. This is reduced by rounding off the corners of the tab.
  • Page 27 Risk Area Crushing/Shear Hazard A crushing/shear hazard is created by the gantry cable web and the frame of the machine. A crushing/pinch hazard is created by the gantry cable web and the gantry. A shearing hazard is created by the carriage and the gantry frame from the back side entry.
  • Page 28 Risk Area Crushing/Shear Hazard A crushing/pinch hazard is created by the gantry and the frame end at these various positions. A crushing/pinch hazard is created by the gantry and the frame rails from the underside. T220UV User Guide...
  • Page 29 Risk Area Crushing/Shear Hazard A crushing/pinch hazard is created by the blotting station. A crushing/pinch hazard is created by the carriage assem- bly at these locations. Note: the carriage assembly cannot move if the gantry doors are open. An impact hazard is created by the movement of the gan- try across the table surface.
  • Page 30 T220UV User Guide...

  • Page 31: User Interface

    Arizona T220UV User Guide Chapter 4 User Interface...

  • Page 32: Operator Control Panel

    The control panel consists of a two line LCD display screen, a key pad, status LED’s and an emergency stop button. A bar code wand, used for scanning ink bottle labels, is stored under the control panel. The Arizona T220UV operator control panel provides access to the printer’s menu system.
  • Page 33 Status Lights The status lights on the control panel have the following fuctions. [14] Control Panel Status Lights Label Function ERROR Indicates a printer problem has occured CHECK Flashes in conjunction with operator alert messages (for example, Blotting cloth low or empty). Indicates a low ink level condition.
  • Page 34 Emergency Stop If a situation requires an immediate shutdown of all printer activity, press one of the three Emergency Stop buttons. To recover from an emergency shutdown, resolve the problem that prompted the shutdown and then release the Emergency Stop by twisting it slightly clockwise.
  • Page 35 Arizona T220UV Lamp Control The UV lamps are necessary for drying the ink. When the lamps are on it is essential to follow the safety precautions indicated in “UV Safety” on page 9, since the UV light is potentially harmful if safety protocol is not followed. This section explains the different states of the lamps and how they relate to the operation of the printer.

  • Page 36: Menu Structure

    Menu Structure Introduction There are three main menus accessed by pressing the MENU key pad. Once you have entered the menu system, press the MENU key to advance the display to the next menu option. Press the ACCEPT key to access a menu’s displayed option. Print Queue Print Jobs ■...
  • Page 37 Maintenance Menu: The Maintenance Menu consists of various commands that support maintenance activities for the printer. The commands are explained in the table below. [18] Maintenance Menu Menu Title Function TURN ON/OFF UV Turn the UV lights ON if you want them to start warming up before you start a print job. This re- LIGHTS duces the wait time between issuing a print job and the time it actually starts.
  • Page 38 Test Prints Menu - The Test Prints menu allows you the option of printing three documents stored in the Arizona T220UV printer: • Nozzle print (Diagnostic and Standard) • Configuration print • Color bars print In the nozzle prints, breaks in the line indicate which heads are misfiring. Performing a High Purge or Recovery Purge on the ink colors that show misfiring can help to clear the affected heads.
  • Page 39 Configure I/O Menu The Arizona T220UV printer can accept input through two types of ports, Centronics parallel, and low-voltage differential (LVD) SCSI-2 communication ports. They are built into the printer. The Active menu allows you to select the type of port - Parallel or SCSI.
  • Page 40 T220UV User Guide...

  • Page 41: How To Operate The Arizona T220Uv

    Arizona T220UV User Guide Chapter 5 How to Operate the Arizona T220UV...

  • Page 42: Training Requirements

    Maximum performance from the Arizona T220UV printer requires a properly trained operator. Océ Service and Support Group trains the operator in the use of the Arizona T220UV hardware and software at installation. However, this is not a substitute for formal PosterShop® training.

  • Page 43: How To Switch The Printer On

    Position the power cord so that it does not pose a hazard when walking around or accessing the doors on the printer. The Arizona T220UV has an AC power circuit breaker that functions as an On/Off switch, and it has an AC power lock-out switch, (it also has an AC power plug, referred to as the Disconnect Device - see below).
  • Page 44 1 - Lockout Device 2 - On/Off Switch 3 - AC Power (Disconnect Device) 4 - SCSI Connector 5 - Parallel Cable 6 - Serial Cable [4] AC Power, Connections & Disconnect Device To Power ON Ensure the red AC power plug is properly seated; and Turn on the AC power circuit breaker On/Off switch.
  • Page 45 [5] Lock-Out / Tag-Out and AC Power Switch Disconnect Device The red AC power plug is the disconnect device for the Arizona T220UV printer. For maximum safety, if the printer Attention: is moved or if any service or repair work is conducted, the disconnect device must first be unplugged from the printer.

  • Page 46: How To Set Up A Print Job

    Select a Print Job Introduction The section explains how to select an image to print on the Arizona T220UV. The image for the print job must first be sent to the printer using Onyx Postershop to prepare a digital image for Note: printing.

  • Page 47: Change Print Job Settings

    When you are at the last digit, pressing ACCEPT advances to the Offests menu. Use the MENU key to move to the next digit if no changes are required for a particular field. Note: How to Operate the Arizona T220UV...
  • Page 48 Change UV Power Setting Use the ACCEPT key to move through the displayed digits. The selected digit has an underline indicating it can be increased or decreased using the + or - keys. When the digit you want to use is displayed, press ACCEPT and the underline moves to the next digit. When you are at the last digit, pressing ACCEPT advances to the Place Media display if Print Parameters were NOT enabled in the Operator/Print Parameters menu.

  • Page 49: Change Print Job Parameter Options

    Printing may not start immediately as the UV lamps must warm up to print temperature so that they can cure the Note: UV-based ink used for imaging on the media. When printing begins, the image start point is the lower left corner of the image. How to Operate the Arizona T220UV...

  • Page 50: How To Use The Media Vacuum

    How to Use the Media Vacuum The Media Vacuum System Introduction The vacuum table is a thin hollow rectangular aluminum box with aluminum box extrusions forming a perimeter frame, two 1/8" aluminum skins forming the top and bottom surfaces, and aluminum honeycomb in the interior supporting the skins. The top surface is drilled with 1mm diameter vacuum holes with a 5mm diameter counterbore to allow air flow into the table and create a vacuum hold-down for the media.
  • Page 51 Press the Vacuum button on the control panel again to turn off the vacuum pump. Note that the location of the zones is also indicated on the table grid. See Appendix A for instructions on how to print Note: the grid onto the table. How to Operate the Arizona T220UV...

  • Page 52: How To Maintain Print Quality

    How to Maintain Print Quality How to Reduce Banding Introduction Banding can occur in an image for a number of reasons. Typically it occurs due to neighbouring nozzles not firing or nozzles firing with poor directionality. This will occur if debris has been picked up from the media or table by a printhead. If this happens, closely inspect the underside of the carriage with a flashlight and remove any debris with a foam-tipped swab.

  • Page 53: Diagnostic Stripe

    Outer Nozzle A B C A B C ……….. A B C A B C Outer Nozzle 1 • • • • • • • • • • • • • • • • .………...• • • • • • • • • • • • • • 128 How to Operate the Arizona T220UV...
  • Page 54 In the Diagnostic Stripe all the ‘A’ nozzles are fired first, then the ‘B’ nozzles and finally the ‘C’ nozzles. Each nozzle is fired 16 times. Refer to "Detail from Diagnostic Stripe". [9] Detail From Diagnostic Stripe [9] Detail From Diagnostic Stripe "C"...
  • Page 55 ‘curtain’ of UV Flush exiting the head is continuous – no gaps or spray in the wrong direction. [11] Five Adjacent Nozzles Not Firing [11] Five Adjacent Nozzles Not Firing Poor Head Position [12] Black Head Poorly Positioned [12] Black Head Poorly Positioned How to Operate the Arizona T220UV...
  • Page 56 The previous example (see figure 12 on page 55) shows that the black head is poorly positioned in the inner carriage. The head is overlapping with its neighbor on the left and there is a gap between it and the head on the right. Also there appears to be a delay before the head fires relative to its neighboring heads, which would indicate that the head is not pushed down fully in its mounting hole.

  • Page 57: Standard Nozzle Print

    Diagnostic Nozzle prints to get more detailed insight into the problem. The Standard Nozzle print is useful for identifying plugged end nozzles and poor directionality. Illustration [14] Standard Nozzle Print [14] Standard Nozzle Print How to Operate the Arizona T220UV...
  • Page 58 How to Use the Standard Nozzle Print Navigate to the Operator/Test Prints menu and select the Standard option to perform a Standard Nozzle Print to verify that all nozzles fire properly. Identify any nozzles that do not fire properly and repeat the nozzle print, preferably on the same media with a slight offset. Perform a High Purge on individual colors for any nozzles that are not working in both previous tests.

  • Page 59: Diagnostic Nozzle Print

    Repeat Nozzle Print. If any nozzles have not fired in all of these nozzle prints, manually flush the print heads associated with those nozzles. Repeat the Nozzle Print and if any heads still have nozzles that do not fire, have them replaced. If you need to replace any heads, contact your Océ service representative. Note: How to Operate the Arizona T220UV...

  • Page 60: Application Hints And Tips

    Application Hints and Tips Introduction The following recommendations are based on our experience with the Arizona T220UV printer. They are offered as staring points or suggestions for dealing with various situations. T220UV User Guide...
  • Page 61 Once reasonable ink restriction values and heater duty cycles are selected, linearization and ICC profiling can be done, if required. How to Operate the Arizona T220UV...
  • Page 62 Situation Solution Imaging off the If anything is printed off the media (e.g., diagnostic stipe or a bleed) use a sacrificial scrap piece of media media - either the same height or up to 1 mm less. Failing to do so causes ink to accumulate on the nozzle plate and may result in banding and over-spray.

  • Page 63: Ink System Management

    Arizona T220UV User Guide Chapter 6 Ink System Management...

  • Page 64: Océ T220Uv Ink

    How to Store and Handle UV Inks To ensure good quality images and to extend the life of printheads in the Arizona T220UV printer, it is important to have good UV ink management procedures. UV inks must be properly handled and stored correctly.

  • Page 65: How To Change An Ink Bottle

    How to Change an Ink Bottle Introduction The ink bottles are located on the Ink Station tray. Ink levels for each bottle are monitored by sensors. Low ink levels are indicated on the control panel display. When to do When the control panel displays an “XXX ink low” message, that particular ink should be replaced. Ink can be replaced at any time, with one exception —...
  • Page 66 To replace an ink bottle Unscrew the lid on a new ink bottle and remove the silver sealing foil. Unscrew the lid on the empty ink bottle and unplug the coupler. Note that the lid stays attached to the ink line and coupler. Put the old bottle aside and immediately place the coupler into the new ink bottle by pushing the flange all the way into the ink pick-up insert.

  • Page 67: How To Scan Ink Barcodes

    How to Scan Ink Barcodes Introduction Whenever you replace an ink bottle, scan the new bottle’s barcode. The T220UV printer calculates the amount of ink used for each color printed and determines approximately when the volume for a bottle of each color ink is finished. It also retains a record of previous barcodes.

  • Page 68: How To Empty The Waste Bottle

    How to Empty the Waste Bottle Introduction The printer accumulates waste that is made up of ink and accumulated debris. The waste bottle is located on the Home side of the gantry and is accessible by opening the gantry doors. A sensor monitors the waste level in the bottle, and a high level is reported on the control panel.

  • Page 69: How To Change Blot Cloth

    How to Change Blot Cloth Introduction The blot station is located in the left side of the gantry, opposite to the Home position. The blot paper is moved up towards the carriage, by means of a single pneumatic cylinder. The blot paper is supplied on a roll and is advanced using a motor. The motor has an encoder and a variable density optical sensor to determine the diameter of the remaining blot paper, and therefore how far the motor needs to turn to advance the correct amount of paper.
  • Page 70 Installing New blot Cloth Remove the old roll of blot cloth and discard. Remove the old empty cardboard core and save it for use in Step 4. Mount a new roll of blot cloth on the lower supports. Run the cloth up the back and over the top of the blot station. Mount the old cardboard core on the upper supports ensuring that the pins on the spindle engage properly with the notched core.

  • Page 71: Media Management

    Arizona T220UV User Guide Chapter 7 Media Management...

  • Page 72: How To Handle Media

    Definition The term media covers a wide range of possible materials for the Arizona T220UV printer. Essentially, any material that is less than two inches (5 cm) thick, more than the minimum size of 6” wide x 6” long (15cm x 15cm) and less than the maximum size of 62”...

  • Page 73: How To Use Media Holder Strips

    How to Use Media Holder Strips Introduction Some media, such as Fome Cor, has a tendency to warp off the table when subjected to heat. This warpage can result in a carriage collision. Media Holder Strips — which are shipped with the printer — help to limit this possibility. Six strips may be required to border the long edges of a sheet of 4'x8' Fome Cor.
  • Page 74 Directions for use: Place the media on the table with a minimum offset of 2"(50mm). Turn on the vacuum. Mask off open vacuum zones with scrap pieces of media less than the height of the media printed on. Push the strips up against the long edges of the media, with the sharp edge protruding into the middle part of the media edge. [23] Sharp edge of the strip against the media.

  • Page 75: Use A Spoilboard Sheet To Reduce Artifacts

    Melanie.Tullis@thermwood.com You can get more information from their website: http://www.woodworkerswholesale.com/ There are 2 spoilboard products from this manufacturer that we recommend for the Arizona T220UV. Part # TA00827 - 1/4"x5'x10' (Actual Size: 1/4" x 61" x 121") Part # TA00826 - 1/4"x4'x8' (Actual Size: 1/4" x 49" x 97") If you think that you need this product, you must buy directly from the manufacturer.
  • Page 76 Tips On How to Use the Underlay Sheet: Use scrap pieces of media to cover any exposed area of the underlay sheet that the carriage will travel over. This prevents the spoilboard sheet from lifting off the table and colliding with the carriage. It may be necessary to bleed the vacuum by opening, or partially opening an additional vacuum zone to reduce dimple artifacts.

  • Page 77: Error Handling And Troubleshooting

    Arizona T220UV User Guide Chapter 8 Error Handling and Troubleshooting...

  • Page 78: Troubleshooting Overview

    On and Off positions, such as '1' for On and '0' for Off. A suitable air gap should be maintained for safe electrical isolation when in the Off position. The Arizona T220UV printer relies on this service for primary branch protection.
  • Page 79 Call for Service Trying to eliminate simple problems before calling your service representative is important, but knowing when to call for service is also important. Without training, servicing the printer yourself may cause further damage. When you have determined that a service call is required, call as soon as possible. Have the following information ready: Printer serial number —...

  • Page 80: Troubleshooting Tips

    Troubleshooting Tips Introduction This section indicates some potential problems you may encounter with your Arizona T220UV Printer and offers possible solutions. If your problem is not solved by these or other suggestions in the Maintaining Print Quality section, place a service call for qualified technical support.
  • Page 81 Problem Solution Problems rotating This is a deficiency in PosterShop. It is best to rotate then crop. If the crop box and image orienta- and cropping tion gets messed up, revert back to the original PostScript settings and try again. Sometimes when images in rotating selecting the “swap width and height”...

  • Page 82: System Errors

    System Errors Introduction System errors stop the printer and prevent operation until the error is resolved. Many system error messages indicate the source of the problem and state that the error can be cleared by pressing the ACCEPT button on the control panel.The following table contains some of the common printer errors.

  • Page 83: T220Uv Lamp Bulb Replacement

    T220UV Lamp Bulb Replacement Introduction This section describes how to change a UV lamp bulb when it burns out. These instructions are also contained in the kit that you receive with a replacement lamp. Note that each kit contains only one lamp, so if both lamps burn out you need to order two kits.
  • Page 84 Illustration [25] Illuminator Lamp on Carriage Side [25] Illuminator Lamp on Carriage Side Procedure for Bulb Replacement If the UV lamps are on (even if one has burned out, the other may still be on) use the Operator/Maintenance/turn on/off uv lamp menu to turn the lamps off.
  • Page 85 Disconnect the thermal sensor cable. [27] Disconnect Thermal Sensor [27] Disconnect Thermal Sensor Disconnect the two lamp connectors. [28] Disconnect Lamp Connectors [28] Disconnect Lamp Connectors Loosen (by hand, but do not remove) the four corner thumbscrews that secure the illuminator in the carriage. [29] Loosen Corner Screws.
  • Page 86 Carefully lift out the illuminator. Place the illuminator on its side on a flat surface and do not lift or move the illuminator during the remaining steps to prevent the quartz window from falling onto the bulb. [30] Remove Illuminator. [30] Remove Illuminator.
  • Page 87 Loosen (but do not remove) both Phillips screws on both side plates that hold the lamp. Pivot the plates out of the way of the bulb. [33] Remove Side Plate Screws [33] Remove Side Plate Screws [34] Pivot Plates out of the way [34] Pivot Plates out of the way Error Handling and Troubleshooting...
  • Page 88 Loosen (but do not remove) both screws (Phillips) on both side plates beneath the bulb and slide out the plates. [35] Remove Screws [35] Remove Screws [36] Slide Plates Out [36] Slide Plates Out T220UV User Guide...
  • Page 89 Put on cotton gloves for the next seven steps. Remove the lamp bulb by carefully sliding the bulb through the housing. [37] Remove Lamp Bulb [37] Remove Lamp Bulb Remove the quartz window by sliding it out very carefully. [38] Remove Quartz Window [38] Remove Quartz Window Gently clean the window using the provided optical cleaning wipes only.
  • Page 90 Return the window into illuminator by carefully sliding it into the housing. Take care not to drop the window onto the bulb. [40] Re-insert Quartz Window [40] Re-insert Quartz Window Return the side plates beneath the bulb by screwing (Phillips) hand tight. Gloves are no longer required. Reconnect the lamp power cables and return them into their brackets.
  • Page 91 Reconnect the ground cable (Allen wrench), the thermal sensor, and two lamp power connectors. [43] Cable, Sensor and Power Connectors [43] Cable, Sensor and Power Connectors Close the gantry doors. Turn the printer power ON. In order to track lamp usage and to estimate lamp replacement schedules, always re-set the usage statistics after Note: replacing a lamp bulb.
  • Page 92 T220UV User Guide...

  • Page 93: Printer Maintenance

    Arizona T220UV User Guide Chapter 9 Printer Maintenance...

  • Page 94: Maintenance Guidelines

    While Océ Display Graphics Systems furnishes guidelines for periodic maintenance, the optimum maintenance schedule evolves from careful observation of your Arizona T220UV printer over a period of use. For example, some specified maintenance may be required each time you use a particular media. The type of print job can also determine the maintenance schedule.

  • Page 95: As Required Maintenance

    As Required Maintenance Remove Ink and Ink Waste Introduction How often you need to perform the following checks and procedures will vary, depending on printer usage and work habits. Remove Ink from Table Clean ink from the table whenever necessary. Once UV ink is cured, the best method for removing it from the table is to use the provided scraper (it is also possible to achieve good results with a razor blade that is set into a handle/holder).

  • Page 96: Clean Carriage Underside

    Clean Carriage Underside Introduction Check the carriage underside on a daily basis to see if it needs cleaning. Otherwise, clean at least once a week. Required tools Poly-Wipe Cloth (0505-0283) Butyl Gloves (3010101760) Safety Glasses Take precautions to avoid ink on your skin or in your eyes. Caution: How to Clean Carriage Underside Use the Access Carriage command from the control panel to automatically move the carriage to the blotting station.

  • Page 97: Swab Printheads

    Swab Printheads Introduction Print heads can become plugged with particulate matter or foreign debris with the result that print quality is reduced. Monitor the diagnostic stripe for signs of banding or overspray, which can be a sympton of plugged printhead nozzles. If you see banding or overspray in a particular color or area of the print, try a Recovery purge and then print the image again.

  • Page 98: Monthly Maintenance

    Monthly Maintenance Clean Gantry Rails Introduction Dust and debris can accumulate on the gantry rails, which run along the length of the table. The bearings that run on the rails are equipped with shields that are designed to keep debris from entering the bearing housing. After a period of time and use, debris can accumulate on the outside of the bearing shields as the gantry traverses the table.

  • Page 99: Clean Gantry Door Fans

    Clean Gantry Door Fans Introduction Inspect and clean the fans located on each of the gantry doors at least once a month, or as needed. In environments where there is a lot of dust and debris in the air, you may need to clean them more frequently. Purpose The fans are important for reducing the buildup of heat within the gantry doors.

  • Page 100: Clean Ozone Filters

    Clean Ozone Filters Introduction Inspect and clean the nine ozone filters located above the fans on the gantry at least once a month, or as needed. In environments where there is a lot of dust and debris in the air, you may need to clean them more frequently. Purpose Good airflow is important to the ability of the filters to absorb ozone.

  • Page 101: Annual Maintenance

    Annual Maintenance Change Auto-Drain Air Filter Introduction The filter element in the air regulator auto-drain must be changed at least once a year. This coalescing filter scrubs any particulate matter out of the printer air supply as the auto-drain removes the moisture. Purpose If the filter element gets too dirty or becomes clogged with particles taken out of the air supply, the ability of the auto-drain to extract moisture from that air is compromised.

  • Page 102: Clean Linear Encoders

    Clean Linear Encoders Introduction The linear encoders allow the gantry and the carriage to maintain the proper speed and orientation during the printing process. The Y-axis encoder strip is located on the gantry and tracks the movement of the carriage across the table. The X-axis encoder stip is located along the length of the table and tracks the movement of the gantry along the table.

  • Page 103: Change The Electronics Bay Air Filter

    Change the Electronics Bay Air Filter Introduction The door for entry to the electronics bay contains a grill for ventilation. The filter in this grill must be inspected periodically and changed when needed. Purpose If the filter is not cleaned or changed when it becomes dirty, the buildup of heat can damage the circuit boards in the enclosure.

  • Page 104: Gantry Brushes (Every Two Years)

    Introduction The Arizona T220UV printer has two brushes on the gantry that act as UV light shields. They are located behind the hinged gates on the BG model and at the base on the gantry cover on the regular model. One is on the front and the other on the back edge of the gantry.

  • Page 105: Special Prints

    Arizona T220UV User Guide Appendix A Special Prints The Operator / Special Prints menu contains two possible selections: the Menu Tree and the Table Grid. If you need an udated version of these print files or if you loose the original file, they are all available for downloading at the ODGS web site T220 customer support page: http://www.oce-dgs.com/PrinterSupport/T220_Customer/ T220_Customer_Access.htm...

  • Page 106: How To Install Special Prints

    How to Install Special Prints Introduction After you download a Menu Tree or Grid Special Print file, transfer it to the T220UV by copying it from the hard drive on the computer. There are two methods for copying files: a) SCSI transfer using T220 Tools software; and b) parallel transfer using a DOS command line.

  • Page 107: How To Print The Menu Tree

    Indoor/Outdoor Poster Grade paper supplied with the printer. Purpose The Menu Tree provides a graphic overview of the complete menu system for the Arizona T220UV printer. Print the Menu Tree In the Control panel menu, navigate to the Operator / Special prints menu.

  • Page 108: How To Print The Table Grid

    How to Print the Table Grid Introduction Table Grid Overview: • The grid can be cleaned off the table and reprinted, as desired. • The data is pre-ripped and ready to print. • The grid file comes in two versions: metric and imperial units. Purpose The table grid file is printed directly on the printer table, and is used to position media for printing.

  • Page 109: Safety Systems And Machine Safeguarding

    Safety Systems and Machine Safeguarding The Arizona T220UV Safety System consists of four redundant systems. These systems are designed to reduce the risk of injuries from moving parts and the UV light source that is necessary for curing the UV-based inks. Although these safety systems keep the potential risks to human operator to a minimum, there are still some possible residual risks.

  • Page 110: Arizona T220Uv Safety Systems

    Introduction Safety Systems and Machine Safeguarding The Arizona T220UV safety system consists of several redundant Safety Systems that are described in this section. Interlock System The interlock system consists of a monitored contact set from the Category Four interlock system and a series circuit of the emergency stop switches that all have normally open contacts (Please see attached schematic Machine Safeguarding Category Four Interlock System T220UVR6MachineSafeGuard.pdf).
  • Page 111 Watchdog Timer System The 48-volt and 24-volt power supplies are controlled by the main gate array (as opposed to the DSP directly) on the DSP board (7500-3007) by means of the spare_ssr_driver. This driver is required to be switched ON in order to enable the power supplies.

  • Page 112: Interlock System Test Procedure

    Interlock System Test Procedure Introduction This section outlines the procedure for testing that all of the safety interlock systems of the T220UV BG model printer are functoning properly. Note that the non-BG model does not have a blue reset button - instead it requires that you release the Emergency Stop by twisting it slightly clockwise, then press ACCEPT to restart the printer.
  • Page 113 Interlock System Test Identify the Front Hinged Gate Interlock Assembly 3010103209 and verify continuity through connections 11/12 and 23/24 with the Gate at 90 degrees vertical. Continuity changes should be observed through pins 1 and 2 on both J2 and J3 (Reference assembly document 3010103209 for pin identification).
  • Page 114 T220UV User Guide...
