Washington - 5drw
Assembly Instructions
Dimensions
Width - 80.3cm
Depth - 45cm
Height - 112.3cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
425/8425
SMOKEY OAK
414/1673
WARM OAK
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
425/8425
414/1673
Issue 1 - 02/07/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Washington 425/8425
Summary of Contents for Argos Washington 425/8425
- Page 1 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed the product, this could cause recommend the on the following pages. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below ID-hole Left side Right side Foldy back (44.9 x 108.9cm) (44.9 x 108.9cm) (79.3 x 102.5cm) P8318...
-
Page 4: Tools Required
Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 a: Screw 24mm locking screw A into left side 1. Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Insert large locking nuts C into left side 1. Make sure the ‘arrow’ on Finished locking nuts C points front edge...
- Page 6 Assembly Instructions Step 2 a: Screw 24mm locking screw A into right side 2. ID-hole Note: Insert 24mm locking Finished screw A as far as shown. front edge Do not over tighten. Insert large locking nuts C into right side 2. Make sure the ‘arrow’...
- Page 7 Assembly Instructions Step 3 Screw 24mm locking screw A into top 4. Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Finished front edge Step 4 Insert expando housing I into Plinth back 8. Step 5 Insert large locking nuts C into bottom 5.
- Page 8 Assembly Instructions Step 6 Attaching panels Position left side 1 and right side 2 onto bottom Use a screwdriver to turn locking nuts C clockwise to lock. Finished front edge Step 7 Attaching panels Position top 4 onto left side 1 and right side 2. Use a screwdriver to turn locking nuts C clockwise Finished...
- Page 9 Assembly Instructions Step 8 Fitting back panel Attach foldy back 3 to the back with the coloured surface facing the inside using nails H. Use nail holder O to hold the nails H vertical and at correct distance as you secure the foldy back 3.
- Page 10 Assembly Instructions Step 10 Screw 24mm locking screw A into drawer front Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Step 11 Position drawer front 7 onto drawer. Use a screwdriver to turn locking nuts B clockwise to lock.
- Page 11 Assembly Instructions Step 12 - continued Fix runner left part B S and runner right part B U using screw E. Slide drawer base support N in corner as shown and fix them, using the attached screw. Step 13 Inserting drawers as shown.
- Page 12 Then snap off flush with the side. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos 03456 400 800...
- Page 13 A Guide to - Drawer adjustment Adjustment Runner left part A x 2 Runner right part A x 2 Note: Each drawer can be adjust for approximately 1mm up or down on each site of the drawer. Remove drawer, adjust the wheel from runner left part A and runner right part A as shown.
-
Page 14: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
