Wow Pine Kitchen Trolley
Assembly Instructions
424/6963
- please keep for future reference
Dimensions
Width - 79.5cm
Depth - 37cm
Height - 82.5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 0845 640 0800
Issue 1 - 21/04/15
Advertisement
Related Manuals for Argos Wow Pine Kitchen Trolley 424/6963
Summary of Contents for Argos Wow Pine Kitchen Trolley 424/6963
- Page 1 Wow Pine Kitchen Trolley Assembly Instructions 424/6963 - please keep for future reference Dimensions Width - 79.5cm Depth - 37cm Height - 82.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Issue 1 - 21/04/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed the product, this could cause recommend the below and on pages 1 and 2.
- Page 3 Components - Panels Please check you have all the panels listed below Left side x 1 Middle upright x 1 Right side x 1 Top x 1 (73.8(h) x 34(d)cm) (72(h) x 34(d)cm) (73.8(h) x 34(d)cm) (65.5(w) x 37(d)cm) Bottom shelf x 1 Wine rack x 2 Shelf x 2 Towel rail x 1...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Note: may be supplied than are required. 40mm Hex bolt x 28 30mm Wooden dowel x 2 30mm Screw x 16 10mm Screw x 2 Drawer stopper x 2 10mm Roundhead screw x 16 Castor with brake x 2...
- Page 5 Assembly Instructions Step 1 Connect 2 x drawer side to 1 x drawer front using 4 x 30mm screw as shown. Step 2 Slide drawer base into slots of sides as shown. Step 3 Connect 1 x drawer back to left and right sides using 4 x 30mm screw as shown.
- Page 6 Assembly Instructions Step 6 Connect 2 x wine rack to middle upright using 4 x 40mm hex bolt as showm. Step 7 Connect 2 x shelf middle upright using 4 x 40mm hex bolt showm. Step 8 Connect 1 x left side to exposed ends of wine racks using 4...
- Page 7 Assembly Instructions Step 9 Connect 1 x right side to exposed ends of shelves using 4 x 40mm hex bolt shown. Step 10 Fix rail to left side using 2 x 40mm hex bolt as shown.
- Page 8 Assembly Instructions Step 11 Connect bottom shelf to legs using 6 x 40mm hex bolt as shown. Step 12 Connect top to top of side and middle panels using 4 x 40mm hex bolt and 2 x 30mm wooden dowel shown.
- Page 9 Assembly Instructions Step 13 Fix 2 x hook to right side using 4 x 12mm screw as shown. Step 14 Connect bracket and storage box using 12mm screws as shown. Step 15 Place storage box onto hooks.
- Page 10 Assembly Instructions Step 16 Insert 2 x basket 2 x drawer completed at Step 3 as shown. Assembly complete.
- Page 12 If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Home Retail Group, 489-499 Avebury Boulevard, Saxon Gate West, Central Milton Keynes, Bucks, MK9 2NW...
