Argos Marlow 424/1195 Assembly Instructions Manual

Argos Marlow 424/1195 Assembly Instructions Manual

5+2 drawer chest

Advertisement

Quick Links

Marlow - 5+2 Drawer Chest
Assembly Instructions -
Dimensions
Width - 72.9cm
Depth - 39.4cm
Height - 128.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
424/1195
400/8785
402/4886
MADE IN
BRITAIN
Issue 2 - 10/06/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the Marlow 424/1195 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Marlow 424/1195

  • Page 1 Marlow - 5+2 Drawer Chest Assembly Instructions - 424/1195 Please keep for future reference 400/8785 402/4886 Dimensions Width - 72.9cm Depth - 39.4cm MADE IN Height - 128.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 2 - 10/06/15...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 45kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Divider (DF3680) (19.5 x 23.6cm) Left Side Right Side (DF3878) (DF3879) (DF3603) (117 x 31.2cm)
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Note: The right drawer front has a small identification hole. Prepare the left and right drawer front Screw 2 metal dowels into the left drawer front .
  • Page 6 Assembly Instructions Step 4 Fit the small drawer base Slide the small drawer base down the grooves in the drawer sides down into the groove in the left and right drawer front Step 5 Fit the small drawer back Fit the small drawer back between the drawer sides Make sure that the small...
  • Page 7 Assembly Instructions Step 8 Prepare the 5 large drawer fronts Screw 2 metal dowels into each of the large drawer fronts Note: Tighten the metal dowels up fully against the panels. Step 9 Attach the drawer sides to the large drawer fronts Push the left drawer sides and right drawer sides...
  • Page 8 Assembly Instructions Step 11 Fit the large drawer back Fit the large drawer back between the drawer sides Make sure that the large drawer base fits into the groove in the large drawer back Hold the large drawer back in position and tap the knock-in pegs through the holes in the drawer sides...
  • Page 9 Assembly Instructions Step 14 Fit 2 legs to the left side Screw 2 legs to the left side using 12 screws Note: The top of the legs must be flush with the top of the left side. Step 15 Fit 2 legs to the right side Screw 2 legs to the...
  • Page 10 Assembly Instructions Step 16 Prepare the left side Place 6 runners the left side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
  • Page 11 Assembly Instructions Step 17 Prepare the right side Place 6 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
  • Page 12 Assembly Instructions Step 18 Finished Prepare the 2 front front edge rails Insert 2 large locking nuts into each of the 2 front rails Tap 2 wooden dowels into each of the 2 front rails Step 19 Fit the front rails to the right side Push the 2 front rails onto the right side...
  • Page 13 Assembly Instructions Step 21 Fit the 2 back rails Push the 2 back rails onto the right side Use a screwdriver to tighten the large locking fitted to each of the 2 back rails Note: Support the 2 back rails until the left side has been fitted in the next step.
  • Page 14 Assembly Instructions Step 24 Prepare the divider Note: Due to the manufacturing process, Finished the 2 holes for the large front edge locking nuts can be on either surface of the divider. Place a runner Finished the divider as shown. front edge Slide back the top of runner and use the 2nd...
  • Page 15 Assembly Instructions Step 25 Remember: The large locking nuts Fit the divider to the can be on either surface of the divider. Push the divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the divider Finished front edge...
  • Page 16 Assembly Instructions Step 27 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 17 If in doubt, consult an expert. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
  • Page 20 ALR3188...

This manual is also suitable for:

Marlow 400/8785Marlow 402/4886
