Malibu - 2 Door Robe
Assembly Instructions -
Dimensions
Width - 75cm
Depth - 49.5cm
Height - 181cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
428/3445
412/3402
414/7756
424/3973
424/7302
MADE IN
BRITAIN
Issue 1 - 21/05/15
Advertisement
Related Manuals for Argos Malibu 428/3445
Summary of Contents for Argos Malibu 428/3445
- Page 1 Malibu - 2 Door Robe Assembly Instructions - 428/3445 Please keep for future reference 412/3402 414/7756 424/3973 424/7302 Dimensions Width - 75cm Depth - 49.5cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 21/05/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 49kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (DF3570) (71.6 x 49.4cm) Left Side Right Side 4 Shelf (DF3568) (DF3569) (DF3579)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left side Fit 3 hinge plates onto the left side making sure that the slot is facing towards the finished front edge.
- Page 6 Assembly Instructions Step 3 Prepare the 2 top/base panels Tap 2 wooden dowels into each of the 2 top/base panels 3 Top/Base 4 Shelf (DF3570) (DF3579) (71.6 x 47.6cm) (71.6 x 49.4cm) Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 7 Assembly Instructions Step 5 Prepare the shelf Tap 2 wooden dowels into the shelf Finished front edge Step 6 Fit the shelf Push the shelf onto the right side secure it with screws Finished front edge Step 7 Prepare the plinth and back rail Tap 2 wooden dowels Finished...
- Page 8 Assembly Instructions Step 8 Fit the plinth and back Finished rail top edge Push the plinth onto the right side secure it with screw Note: Support the Push the back rail back rail until the left onto the right side side has been fitted and secure it with screw in the next step.
- Page 9 Assembly Instructions Step 10 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 10 Assembly Instructions Step 12 Fit the hanging rail Push the hanging rail into the rail holders Step 13 Prepare the 2 doors Push fit 3 hinges into each of the 2 doors Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees...
- Page 11 Assembly Instructions Step 14 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 12 Assembly Instructions Step 15 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 13 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 15 ALR3190...
