Normandy - 5 Drawer Chest
Assembly Instructions -
Dimensions
Width - 75cm
Depth - 39.6cm
Height - 90.8cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
428/2611
414/2081
411/7717
MADE IN
BRITAIN
Issue 1 - 21/05/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Normandy 428/2611
Summary of Contents for Argos Normandy 428/2611
- Page 1 Normandy - 5 Drawer Chest Assembly Instructions - 428/2611 Please keep for future reference 414/2081 411/7717 Dimensions Width - 75cm Depth - 39.6cm MADE IN Height - 90.8cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 21/05/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 33kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below 3 Top (D2363A) (75 x 39.6cm) Left Side Right Side Rail (DF3875) (DF3876)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Large locking Wooden dowel Metal dowel x 18 (F22) (F901)
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 5 drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Step 2 Prepare the drawer...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides then down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place 5 runners left side . Slide back top of runner and use 2nd hole from the front to fit 1st screw Finished Slide the runner front edge back the other way and fit the 2nd screw into the corresponding hole...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place 5 runners right side . Slide back top of runner and use Finished 2nd hole from the front front edge to fit 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 10 Prepare the 3 rails Insert 2 large locking nuts into each of the rails Tap 2 wooden dowels into each of the rails Step 11 Fit the 3 rails Push the 3 rails onto right side as shown.
- Page 10 Assembly Instructions Step 12 Fit the left side Fit the left side to the 3 rails Use a screwdriver to tighten the large locking fitted to each of the rails Carefully stand the unit up. Warning: The unit is heavy. Lift with care.
- Page 11 Assembly Instructions Step 14 Fit the top Lower the top onto the side panels Use a screwdriver to Rounded tighten the 2 large front edge locking nuts fitted to the inside of the left side and right side Carefully lay the unit down onto its front again.
- Page 12 Assembly Instructions Step 16 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Carefully stand the unit up for the next step. Warning: The unit is heavy. Lift with care. Step 17 Fit the drawers Starting with the bottom drawer, slide both the...
- Page 13 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3173...
