Marlow - 2 Door Robe
Assembly Instructions -
Dimensions
Width - 91.1cm
Depth - 49.5cm
Height - 191.8cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
424/2929
404/2260
395/5530
MADE IN
BRITAIN
Issue 1 - 22/05/15
Advertisement
Related Manuals for Argos Marlow 424/2929
Summary of Contents for Argos Marlow 424/2929
- Page 1 Marlow - 2 Door Robe Assembly Instructions - 424/2929 Please keep for future reference 404/2260 395/5530 Dimensions Width - 91.1cm Depth - 49.5cm MADE IN Height - 191.8cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 22/05/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 58kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Horizontal (DF3930) (79.7 x 45.9cm) Rail (DF3742) (79.7 x 11.9cm) Left Side Right Side (DF3918)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Fit 2 legs to the left side Screw 2 legs to the left side using 18 screws Note: The top of the legs must be flush with the top of the left side.
- Page 6 Assembly Instructions Step 3 Prepare the left side Screw 5 metal dowels into the left side Note: Tighten the metal dowels up fully against the panels. Tap 2 wooden dowels into the left side Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 7 Assembly Instructions Step 5 Prepare the 2 horizontals Insert 4 large locking nuts into each of the horizontals Finished Note: The arrow on the front edge locking nut must point towards the hole in the edge of the panel. Tap 2 wooden dowels into each of the horizontals Step 6...
- Page 8 Assembly Instructions Step 8 Fit the rail Push the rail onto the right side Use a screwdriver to Finished tighten the large locking front edge fitted to the rail Note: Support the rail until the left side has been fitted in the next step.
- Page 9 Assembly Instructions Step 10 Fit the top Attach the top to the sides using the 4 screws Finished front edge Step 11 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x...
- Page 10 Assembly Instructions Step 12 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 13 Prepare the 2 doors Push fit 3 hinges into each of the 2 doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 11 Assembly Instructions Step 14 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 12 Assembly Instructions Step 15 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 13 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3182...
