Argos New Sywell 427/1237 Assembly Instructions Manual
Argos New Sywell 427/1237 Assembly Instructions Manual

Argos New Sywell 427/1237 Assembly Instructions Manual

2 door sliding robe

Advertisement

Quick Links

New Sywell - 2 Door Sliding Robe
Assembly Instructions -
Dimensions
Width - 101.9cm
Depth - 59.5cm
Height - 171.1cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
427/1237
427/1244
425/8700
427/1770
MADE IN
BRITAIN
Issue 1 - 28/05/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the New Sywell 427/1237 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos New Sywell 427/1237

  • Page 1 New Sywell - 2 Door Sliding Robe Assembly Instructions - 427/1237 Please keep for future reference 427/1244 425/8700 427/1770 Dimensions Width - 101.9cm Depth - 59.5cm MADE IN Height - 171.1cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 28/05/15...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 62kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Divider (DF3581) (DF3582) (DF3585) (171.1 x 59.2cm) (171.1 x 59.2cm) (165.6 x 49.6cm) Top/Base...
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the top and base Place 2 plastic tracks down onto each of the and base panels, making sure that they are flush with the edges of the panel.
  • Page 6 Assembly Instructions Step 2 Prepare the divider Tap 4 wooden dowels into the divider Fit a rail holder screwing through the top hole with screw into the mark hole drilled in the divider . Make sure that it is fitted straight, in line with the Finished front edge...
  • Page 7 Assembly Instructions Step 3 Fit the top and base to the divider Attach the top the base to the divider using 4 screws Base Note: The plastic tracks must be on the inside surfaces of the top and base Step 4 Prepare 1 of the shelves Tap 2 wooden dowels...
  • Page 8 Assembly Instructions Step 5 Fit the shelf Push the shelf onto the divider Tap 2 double metal dowels through the divider and into the shelf until they ‘’bottom out’’. Tap 2 large wooden dowels through the divider and into the shelf until they Finished...
  • Page 9 Assembly Instructions Step 7 Plain chipboard surface Prepare the 2 rails Finished Insert 4 large locking front edge nuts into each of the 2 rails Step 8 Fit a rail Plain chipboard Tap 2 double metal surface dowels through the divider and into a rail until they ‘’bottom...
  • Page 10 Assembly Instructions Step 9 Fit the left side Push the left side onto the assembly. Tap 2 mushroom head pins into the holes on the outside of the left side Use a screwdriver to tighten the 8 large locking nuts fitted to the top , base...
  • Page 11 Assembly Instructions Step 11 Fit the other shelf Push the shelf onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the shelf Step 12 Prepare the right side Screw 6 metal dowels into the right side Note: Tighten the metal dowels up fully against the panels.
  • Page 12 Assembly Instructions Step 13 Plain chipboard surface Fit the other rail Finished front edge Push the rail onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the rail Note: Support the rail until the right side has been fitted in the next step.
  • Page 13 Assembly Instructions Step 15 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit back panels Square up the unit by making sure that measurement x:x equals y:y.
  • Page 14 Assembly Instructions Step 16 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Screw the 2 feet down the middle of the Warning: The base , 1 near the front unit is heavy. and 1 near the back, Lift with care.
  • Page 15 Assembly Instructions Step 18 Prepare the right hand door Important: Check that the holes are in the same place as the diagram. Push 2 top glides into 1 of the doors Push 2 bottom glides into the same door This will be the and secure each one right hand door with 2 screws...
  • Page 16 Assembly Instructions Step 20 Fit the doors With the top of the right hand door leaning back at an angle, insert the bottom glides into the rear track Push the top of the right hand door in and locate the top glides into the rear track Buffer bracket Right...
  • Page 17 Assembly Instructions Step 21 IF YOUR DOORS DO NOT RUN SMOOTHLY Adjust the doors if needed If your doors are not running smoothly, please follow these instructions to adjust the bottom glides. Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown.
  • Page 18 Assembly Instructions Step 22 Attach the handles Attach a handle each of the doors using screws...
  • Page 19 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
  • Page 20 ALR3192...
