Washington - 02BS
Assembly Instructions
Dimensions
Width - 43.8cm
Depth - 37.3cm
Height - 54.7cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
392/3342
SMOKEY OAK
427/1433
WARM OAK
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
392/3342
427/1433
Issue 1 - 02/07/15
Advertisement
Related Manuals for Argos Washington 02BS
Summary of Contents for Argos Washington 02BS
- Page 1 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed the product, this could cause recommend the on the following pages. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below ID-hole Left side Right side Foldy back (37.1 x 51.3cm) (37.1 x 51.3cm) (42.9 x 44.9cm) P2018...
-
Page 4: Tools Required
Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 a: Screw 24mm locking screw A into left side 1. Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Insert large locking nuts C into left side 1. Make sure the ‘arrow’ on Finished locking nuts C points front edge...
- Page 6 Assembly Instructions Step 2 a: Screw 24mm locking screw A into right side 2. Finished ID-hole front edge Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Insert large locking nuts C into right side 2. Make sure the ‘arrow’...
- Page 7 Assembly Instructions Step 3 Screw 24mm locking screw A into top 4. Note: Insert 24mm locking screw A as far as shown. Do not over tighten. Finished front edge Step 4 Insert large locking nuts C into bottom 5. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of bottom 5.
- Page 8 Assembly Instructions Step 6 Attaching panels Position top 4 onto left side 1 and right side 2. Use a screwdriver to turn locking nuts C clockwise to lock. Finished front edge Step 7 Fitting back panel Attach foldy back 3 to the back with the coloured surface facing the inside using nails G.
- Page 9 Assembly Instructions Step 8 Preparing drawer Insert locking nuts B into left drawer side 8 and right drawer side 0. Make sure the ‘arrow’ on locking nuts B points towards the hole in the edge of 8 and 0. Put drop of glue Q into the 3 holes of left drawer side 8 and right drawer side 0.
- Page 10 Assembly Instructions Step 10 Position drawer front 7 onto drawer. Use a screwdriver to turn locking nuts B clockwise to lock. Note: look carefully to the positions of drawer front 7. Fix drawer handle H onto drawer front 7 using screw F.
- Page 11 Then snap off flush with the side. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos 03456 400 800...
- Page 12 A Guide to - Drawer adjustment Adjustment Runner left part A x 2 Runner right part A x 2 Note: Each drawer can be adjust for approximately 1mm up or down on each site of the drawer. Remove drawer, adjust the wheel from runner left part A and runner right part A as shown.
