Marlow - 1 Drawer 3 Door Robe

Assembly Instructions -

Dimensions

Width - 130.8cm

Depth - 49.5cm

Height - 191.8cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, please visit www.argos-support.co.uk

or email: Help@ClickSpares.co.uk (quoting your original order number)

Alternatively, call the Spares Helpline on: 0370 112 1928.

For any other queries please contact the Customer Helpline on: 0345 640 2020

Please keep for future reference

425/8009

427/7059

426/9768

MADE IN

BRITAIN

Issue 1 - 02/07/15

Need help?

Do you have a question about the Marlow 425/8009 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Marlow 425/8009

Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
Page 2 Take to your local authority waste disposal centre. Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 8 Fit 2 legs to the left side Screw 2 legs to the left side using 18 screws Note: The top of the legs must be flush with the top of the left side. Step 9 Fit 2 legs to the right side Screw 2 legs to the...
Page 8 Assembly Instructions Step 10 Prepare the left side Place a runner the left side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
Page 9 Assembly Instructions Step 11 Prepare the right side Screw 3 metal dowels into the right side Tap 2 wooden dowels into the right side Fit 3 hinge plates onto the right side , making sure that the slot is facing towards the finished front edge.
Page 10 Assembly Instructions Step 13 Prepare the divider Place a runner the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
Page 11 Assembly Instructions Step 14 Fit the large shelf Push the large shelf onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to Finished the large shelf front edge Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Page 12 Assembly Instructions Step 16 Fit the base to the divider Attach the base the divider using 2 screws Finished front edge Step 17 Prepare the small rail Insert 2 large locking nuts into the small rail Finished front edge Tap a wooden dowel into small rail...
Page 13 Assembly Instructions Step 18 Fit the small rail Note: Support the Position the small rail small rail until the up against the 2 right side has been fitted in the next step. holes in the divider Tap a double metal dowel through the divider...
Page 14 Assembly Instructions Step 20 Prepare the large rail Insert 2 large locking nuts into the large rail Finished front edge Tap a wooden dowel into large rail Step 21 Fit the large rail Push the large rail onto the divider Use a screwdriver to tighten the arge locking fitted to the large...
Page 15 Assembly Instructions Step 22 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 5 large locking nuts fitted to the large rail , the large shelf and the base Step 23 Prepare the foot Tap a wooden dowel into the foot...
Page 16 Assembly Instructions Step 24 Fit the foot Push the foot onto the base and secure it using screw Step 25 Fit the top Attach the top to the sides and the divider using the 6 screws Finished front edge...
Page 17 Assembly Instructions Step 26 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the 2 back panels Square up the unit by making sure that measurement x:x equals y:y.
Page 18 Assembly Instructions Step 27 Fit the hanging rail Push the hanging rail into the rail holders Step 28 Fit the drawer Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners...
Page 19 Assembly Instructions Step 29 Fit the shelf studs For each of the 3 small shelves , insert 4 shelf studs at the required height. Step 30 Fit the 3 small shelves Lower the 3 small shelves down onto the shelf studs...
Page 20 Assembly Instructions Step 31 Prepare the 3 doors Push fit 3 hinges into the left door , the middle door and the right door Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are positioned at 90 degrees with the edge of the door.
Page 21 Assembly Instructions Step 32 Fit doors and handles Note: The easiest way to attach each door 18 19 and . is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
Page 22 Assembly Instructions Step 33 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 23 Assembly Instructions Step 34 Screw Fit the overbalance Washer protector Wall fixing Strap (not supplied) Strap To prevent possible Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by fitting of the overbalance protector kit to the unit, or an alternative fixing method of your choice.
Page 24 Assembly Instructions Step 35 Assembly is complete If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...

This manual is also suitable for:

Marlow 427/7059 Marlow 426/9768
