USA/Canada/Mexico Japan Europe Australia United Kingdom Model 1005 24-Port Ethernet Hub (E-TBT-HB-1005) 7368.D For assistance in installing, using, or maintaining the TRANSITION Networks Model 1005 Ethernet™ Repeater Hub, contact TRANSITION Networks Technical Support (800) 260-1312 or contact your local distributor.
Page 2
TRANSITION Networks Inc. Trademark Notice All registered trademarks and trademarks are the property of their respective owners. Model 1005 24-Port 10Base2 Cable Specifications The physical characteristics of the 10Base2 cable must meet or exceed IEEE 802.3 10Base2 specifications.
This guide is intended for the system or network administrator responsible for installing and monitoring a TRANSITION Networks Model 1005 24-Port Ethernet™ Repeater Hub. A working knowledge of local area network (LAN) operations, including familiarity with communications protocols used on interconnected LANs, is assumed.
CUSTOMER OF THE POSSIBILITY OF SUCH DAMAGES IN ADVANCE OF THIS SALE. Model 1005 24-Port Networking the Model 1005 Repeater Hub The Model 1005 Repeater Hub can be installed in an Ethernet network by connecting 10BaseT cable between RJ-45 connectors on the front of the hubs.
Twenty-four (24) RJ-45 10BaseT connectors are located on the front of the Model 1005 Repeater Hub. One (1) power connector is located on the back of the Model 1005 Repeater Hub. NOTE: Slide-In cards (SICs), if installed at the back of the Model 1005, provide additional fiber optic, male and female AUI, BNC, or RJ-45 connectors.
The Model 1005 Repeater Hub requires no intervention beyond occasionally monitoring the Power and Status LEDs. Monitoring Power LED The Power LED displays a steady green light when the Model 1005 Repeater Hub is connected to power. Monitoring Status LEDs...
• Install fuse holder in correct rating orientation. • Close fuse receptacle. 3. Plug unit end (female) of power cord into Model 1005 Repeater power receptacle. 4. Plug outlet end (male) of power cord into correct voltage AC wall socket.
The 10BaseT cable and RJ-45 jacks for Hub to Hub connections must be configured as crossover. NOTE: When installing the 1005 Hub using the MDI port, a crossover cable is not needed. The MDI switch can be used to change the straight through configuration to crossover at port 1.
Connect Cable to SIC and RJ-45 connector. • Connect Model 1005 Repeater Hub to power. Direction is provided in the pages that follow. Unpacking the Model 1005 Repeater Hub The Model 1005 Repeater Hub packing contents should include the following: Item Part Number Model 1005 Hub...
Twisted Pair Connector/10BaseT Connection To connect 10BaseT Cable to Model 1005 Repeater RJ-45 connectors: 1. Locate or build 10BaseT cables that are: • 802.3 compliant (See page 18) • correct (straight through or crossover) cable configuration for site installation (See page 6) •...
3. Install two screws through right front bracket and two screws through left front bracket, using clip nuts if necessary. To install the Model 1005 Repeater on table or other flat surface: 1. Carefully turn Model 1005 Repeater Hub to side.
