LANMASTER T8 8-PORT HUB

SPECIFICATIONS

Standards
IEEE 802.3
Physical
Dimensions
137 mm x 137 mm x 25 mm
Power
Power Supply Adapter
AC Input (47-63 hertz):
PN
Requirement
3532
120 volts, 60 hertz, 28 watts
3535
230 volts, 50 hertz, 28 watts
3534
100 volts, 50-60 hertz, 28 watts Japan
3533
240 volts, 50 hertz, 28 watts
3536
240 volts, 50 hertz, 28 watts
DC Output:
12 volts at 800 mA maximum.
Environment
Temperature:
0-50°C (32° to 122° F )
Humidity
10-90%, non condensing
Altitude
0-10,000 feet
Warranty
Lifetime
21
Location
USA/Canada/Mexico
Europe
United Kingdom
Australia
LANMaster™ T8
8-Port Ethernet™ Hub
(E-TBT-HB-0804)
For assistance in installing, using, or
maintaining the TRANSITION Networks
LANMaster T8 8-Port Ethernet™
Repeater Hub, contact TRANSITION
Networks Technical Support
(800) 260-1312
or contact your local distributor.
33022.B
at:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAN MASTER 33022.B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transition Networks LAN MASTER 33022.B

Summary of Contents for Transition Networks LAN MASTER 33022.B

  • Page 1: Specifications

    USA/Canada/Mexico Europe United Kingdom Australia LANMaster™ T8 8-Port Ethernet™ Hub (E-TBT-HB-0804) 33022.B For assistance in installing, using, or maintaining the TRANSITION Networks LANMaster T8 8-Port Ethernet™ Repeater Hub, contact TRANSITION Networks Technical Support (800) 260-1312 or contact your local distributor.
  • Page 2 Copyright Restrictions © 1997 TRANSITION Networks. All rights reserved. No part of this work may be reproduced or used in any form or by any means – graphic, electronic, or mechanical – without written permission from TRANSITION Networks.

  • Page 3: Table Of Contents

    ETHERNET CABLE SPECIFICATIONS Maximum number of terminal devices on Ethernet network: 10BASE-5 Cable and Connector Specifications The physical characteristics of the 10BASE-5 cable must meet or exceed IEEE 802.3 10BASE-5 specifications. 10BASE-5 Cable Characteristics: Cable type: RG8 Solid Coaxial (ThickNet) Impedance: Capacitance: 26pF/ft...

  • Page 4: Introduction

    • The item(s) may be shipped by the customer or the distributor. • Transition Networks will repair or replace the unit, at TN’s discretion, and cover the cost of the return freight to the distributor or to the customer, whichever requested the RMA number.

  • Page 5: Networking The Lanmaster T8

    Warranty Statement A. Five Year Warranty Transition Networks, Inc. (TN) warrants, for a period of five years, that TN products (with the exception of power supplies and fans that TN warrants for two years) will be free from defects in materials and workmanship, and will be in conformity with TN’s specifications.

  • Page 6: Connectors And Indicators

    Connectors and Indicators CONNECTORS Straight-through RJ-45 Connectors – Crossover RJ-45 (X) Connector Eight (8) straight-through RJ-45 connectors, labeled 1-8, and one (1) crossover RJ-45 connector, labeled X, are located on the front of the LANMaster T8. Power Adapter Connector LED Indicators 1 2 3 4 5 6 7 8 Link Status...

  • Page 7: Operation

    4. OPERATION The LANMaster T8 requires no intervention beyond occasionally monitoring the Power and Status LEDs. 1 2 3 4 5 6 7 8 Link Status 1 2 3 4 5 6 7 8 Link Status Monitoring Status LEDs Steady green Act(ivity) LED indicates connection of the LANMaster T8 to external AC powerr.

  • Page 8: Installation

    3. INSTALLATION To install the LANMaster T8: • Unpack the LANMaster T8 • Install LANMaster T8 at site • Install Network Cable • Power the LANMaster T8. Direction is provided in the pages that follow. Unpacking the LANMaster T8 The LANMaster T8 packing contents should include the following: Item Part Number LANMaster T8 Hub...

  • Page 9: Installing Lanmaster T8 At Site

    Installing Thicknet 10BASE-5 Cable The LANMaster T8 provides a female AUI connector at the back for network connection to 10BASE-5 through an AUI drop cable or to 10BASE-2, 10BASE-T, or 10BASE-FL through a transceiver. CONNECTING TO 10BASE-5 USING AUI DROP CABLE To connect to 10BASE-5 cable using AUI drop cable: 1.

  • Page 10: Installing Network Cable

    Installing Network Cable 10BASE-T Requirements STRAIGHT-THROUGH/CROSSOVER CABLE/CONNECTOR NOTE: The 10BASE-T cable and RJ-45 jacks for hub to terminal device connections must be configured as straight through. The 10BASE-T cable and RJ-45 jacks for hub to hub connections must be configured as crossover.

  • Page 11: 10Base-2 Requirements

    Installing Twisted-Pair 10BASE-T Cable To connect 10BASE-T Cable to LANMaster T8 RJ-45 connectors: 1. Locate or build 10BASE-T cables that are: • 802.3 compliant (See page 20.) • straight through connector/cable configuration (See with page 7.) • male RJ-45 plug connectors at both ends. with 2.

  • Page 12: 10-Mb/S Network Configuration Guidelines

    10-Mb/s Baseband Network Configuration Guidelines Ethernet 802.3 specifications define network configuration guidelines for the 10-Mb/s baseband network: 10BASE-T, 10BASE-2, and 10BASE-5 cable segments can be installed as a single Ethernet collision domain if the cable segments are connected using repeaters. When connecting LANMaster T8 repeater hubs, the transmission path between any two Data Terminating Equipment (DTE) network devices...
