F a s t l a n e S w i m U n i t I n s t a l l a t i o n
®
Deck Mount Accessories Kit
- 1 Top Lid, Sapphire, Acrylic Pool Propulsion Housing
D
- 2 Protective Hat Channels
- 1 Deck Plate Hanging Bracket
- 1 Deck Plate Cover
- 1 Deck Plate Bottom
- 1 Bonding Lug, 3/16" (4,8mm) Stud Size
- 1 Screw, 316 SS, M/S, Phillips, Truss, 10-32 x 3/8" (9,5mm)
- 2 8 JIC Female x 6 JIC Male Adapter
- 8 Masonry Screws, 3/16 x 2-1/4" (4,7mm x 57mm), Phillips Flat Head, Blue Coated Steel
- 4 Hose Clip
- 1 Bit, Masonary, 5/32" (4mm)
- 18 Screw, #10 x 3/4" (19mm), SMS, Blunt Tip, Phil Truss Head,
Type B Point, Type A Thread, Passivated 316SS
- 8 Screw, 316L SS, M/S, Phillips Truss 10-32 x 1/2" (12,7mm)
- 16 Screw, #10 x 1" (25mm), SMS, Blunt Tip, Phil Truss Head,
Type B Point, Type A Thread, Passivated 316SS
- 1 Zinc Sacrificial Anode
- 16 Screw, 316 SS, M/S, Type 1 Phillips Truss Head, 10-32 x 1" (25mm)
- 6
The Following two packages will be included ONLY if a Wall Mount Fastlane was purchased:
Parcel 6: Wall Mount Bracket Assembly
W
Optional Equipment
• Outdoor Power Unit with Weather Guard
W D
• Floor Mirror
• Swim Pace Display
Section 4

WALL MOUNT BRACKET

NOTE: Please read instructions fully before beginning bracket installation.
4.A. Gunite/Concrete Pool
W
If the pool being constructed is gunite or concrete, please follow the instructions below.
Parcel 6 includes the Wall Mount Fastlane bracket for concrete or gunite pools. (refer to Photo 4.A.1)
- 1 Gunite/Fiberglass Wall Bracket PVC Plate
- 1 Screw, 316L SS, M/S, Phillips Truss 10-32 x 1-1/2" (38mm)
- 1 Bonding Lug, 3/16" (4,8mm) Stud Size
- 1 Washer, Flat, #10 x 7/16OD x .062 Thick, 316 SS
- 1 Nut, Jam, 10-32, 316SS
- 1 Nut, 316 SS, Lock, Hex, w/ Nylon Insert, 10-32
- 2 Threaded Rod, 3/8-16, 316 SS, 10.25 in long (26cm)
- 6 Nut, Jam, 3/8-16, 316SS
- 6 Washer, 316 SS, Flat, 3/8" x 7/8" (9,5mm x 22mm)
- 2 Washer, 316 SS, Lock, Medium Split, 3/8" (9,5mm)
- 2 Thruwall Fitting, PVC, Schedule 40, Round Cutout, 1-1/2" (38mm) FSlip
- 2 Bushing, PVC, Reducer, 1-1/2" (38mm) MPT x 1" (25,4mm) FPT
- 2 Cord Grip Liquid Tite Fitting, PVC, 1" (25,4mm) NPT, fitting only
3
Nut, 316 SS, Lock, Hex, with nylon insert, 10-32
