Endless Pools Fastlane Owner's Manual page 23

• If the hoses attached to the Fastlane are to be directly connected to the Power Unit, the
use the adapters (-8 female JIC x –6 male JIC) that were provided in the Accessories Kit.
• If the 1/2" (12,7mm) run hoses are to be attached to the Power Unit, then these hoses will connect
directly to the appropriate connections on the power unit.
12.6 Remove the oil filter by lifting it out of the fill opening. Fill the Power Unit with the approxi-
mately four (4) gallons (14L) of hydraulic fluid provided. (The fill cap is at the low-pressure
fitting.) Once filled with oil, replace the oil filter and cap and press firmly to ensure proper seating
of the filter. Turn circuit breaker on. Install antenna and test the Power Unit operation using the
remote control.
12.7 Once the Fastlane is fully installed and operational, turn the system off and disconnect the hydraulic
return hose which connects to the fill cap port (red tape). Place this hose end into an empty 5-gallon
(19L) bucket.
12.8 Turn on the Fastlane, making sure to hold the hose firmly in your hand over the bucket. The
returning hydraulic fluid will flow into the bucket. The system will automatically shut off when
the float level switch inside the fluid reservoir is tripped.
12.9 TURN OFF POWER TO THE UNIT AT THE CIRCUIT BREAKER.
12.10 Reconnect the hose to the power unit and tighten. Open the fill cap and add a little more than
one cup of hydraulic fluid back to the reservoir. Reattach the fill cap to the power unit.
12.11 Restore power and test the unit. It should stay on continuously. (If it turns off, even intermit-
tently, turn off the power, add 1 cup of oil (approx 250ml), restore electrical power, and re-start
the unit).
Section 13 USING YOUR FASTLANE
The Fastlane features 52 incremental steps in speed. Press and release the FASTER button to increase
the speed of the current one step at a time. Alternatively, press and continue to hold the FASTER button
W D
to ramp up the speed until the button is released or the maximum speed is achieved. Reduce the speed
in the same manner using the SLOWER button.
Turn off the Fastlane by again pressing the ON/OFF button.
The Power Unit remote control is equipped with an automatic timer shutting off the system 30 minutes
after receiving its last command. Because the Fastlane "remembers" the speed at which it was turned
off, it will return to that same pace when it is turned back on.
Section 14 GENERAL INFORMATION
Once installed, the Fastlane will provide years of exercise and fun with minimal maintenance. Clean the
intake grills of leaves as needed and wipe down the stainless steel cylindrical base and grab rail with
W D
warm water, a Scotch Brite pad, and brisk rubbing. Clean the acrylic housing with any typical non-am-
monia, non-abrasive kitchen cleanser. Periodically, check all electrical and ground wire connections and
test the GFCI circuit breaker for proper function.
It is important for the long-term operation of your Fastlane that your pool water be properly balanced
and in accordance with normal pool industry standards. In addition, it is imperative that the Fastlane be
bonded to the pool bonding grid.
Endless Pools is an industry leader in customer service, should you ever have questions or concerns
about your Fastlane, please contact our Customer Service Department at 800-910-2714 (US),
0800-520-0196 (UK) or 610-497-4538 (Direct).
Section 15 SCHEDULED MAINTENANCE
15.1 Hydraulic Motor and Fluid Maintenance. We recommend the hydraulic motor, which is located
in your swim unit and submerged underwater, be replaced after six years of usage. We also recom-
W D
mend changing the non-food grade, biodegradable vegetable oil and filter in the Power Unit after
every 500 hours of use.
15.2 Grill Cleaning. Should you perceive a reduction in speed of your Fastlane, it may be caused by a
reduction in water flow due to a blockage of the inlet assembly of the cylindrical base. Because the
underside of your Fastlane will be sucking in water, it may occasionally become necessary to clean
the cylindrical base of any debris or leaves that may have been in your pool when the Fastlane was
in operation. With the Fastlane unit turned off, this is very easy to accomplish while in the pool.
F a s t l a n e S w i m U n i t I n s t a l l a t i o n
®
2 2
