Endless Pools Fastlane Owner's Manual page 18

F a s t l a n e S w i m U n i t I n s t a l l a t i o n
®
Section 8 DECK MOUNT FASTLANE HOSE COVER TRAY INSTALLATION
8.1 Choose where the Fastlane is to be placed in the pool. The water depth must be 35" (89cm). There must
be a minimum of 24" (61cm) between the Fastlane and any adjacent wall or pool obstruction.
D
8.2 Position the hose cover tray onto the pool deck so that the vertical lip of the tray is seated firmly against
the coping. The tray will be centered to the Fastlane. If the pool has bullnose coping it is acceptable for
the hose cover tray to be slightly out of level as shown in figure 8.1.
8.3 Use the provided 5/32" (4mm) drill bit to drill a hole into the deck approximately 2" (50,8mm) deep
through the two holes in the rear of the tray. While these 2 screws are enough to secure the Fastlane to
the pool wall, extra anchor screws have been provided for additional anchor points if desired.
1 7
Fig. 8.1
Fig. 8.2
