Endless Pools Fastlane Owner's Manual page 21

Section 10 ELECTRICAL REQUIREMENTS FOR THE UNITED STATES (and countries with similar electrical requirements)
W D
optional
PACE
DISPLAY
RJ-14
Section 11 ELECTRICAL REQUIREMENTS FOR THE UK (and countries with similar electrical requirements)
The unique design of the Fastlane facilitates sales to UK and international customers. The Fastlane is
shipped in kit form for easy assembly and installation into any new conventional pool following the de-
W D
tailed instructions provided.
The Fastlane is ETL marked and CE listed.
The Power Unit circuit must be RCD (GFI) protected. The MCB (breaker) that operates the hydraulic
Power Unit should be Ç-type or motor-rated.
United States wire color-coding is different than international color-coding. The following chart identifies
the color-coding used in the United States as it relates to the wire type. In addition, the wires of the con-
troller have a short, colored sleeve wrapped around them to conform to the international color codes.
Black with Brown Sleeve
Red with Blue Sleeve
Green with Green/Yellow Sleeve
Should you have any questions, please call the Customer Service Department at 800-910-2714 (US),
0800-520-0196 (UK) or 610-497-4538 (Direct), or email us at poolhelp@endlesspools.com.
EP1 CONTROLLER
4-20 mA OUT
4-20 mA COM
Antenna
24 COM
24 VDC
SOL +
RJ-14
SOL -
R2
R4
GND
B R
G/y B W
Line 1
B
Line 2
R
Neutral
W
Ground
G/y
WIRING DIAGRAM
5 & 7.5 HP, 60 Hz. EP-1 CONTROLER
Wire Color US Wire Type (60Hz)
Hot or Live (120v)
Hot or Live (120v)
F a s t l a n e
CIRC. SAVER IN
CIRC. SAVER
LINE ONE IN
LINE TWO IN
(NEUTRAL)
SWITCHED OUT
SWITCHED IN
B
2P/2T
W
Contactor
R
R1
C
N
2 1
NO
4 3
NO
R3
C
N
Line 1
B
Line 2
A2 A1
R
Ground
G/y
B
W
B
Int. Wire Type (50Hz)
Ground
S w i m U n i t I n s t a l l a t i o n
®
HYDRAULIC POWER UNIT
W B
Float
Level
Switch
on HPU
Proportional
Valve
Hydraulic
Power Unit
(HPU)
G/y
DRAWING/PART NUMBER: REVISION:
WD0003
Hot or Live (220v)
Neutral
Earth
B
2 0
