Endless Pools Fastlane Owner's Manual page 24

F a s t l a n e S w i m U n i t I n s t a l l a t i o n
®
15.3 Cold Weather Maintenance. At the end of the swimming season, it is recommended the Fastlane
Swim Unit be removed from the swimming pool and winterized. For specific instructions, please
W D
contact our Customer Service Department at 800-910-2714 (US), or 610-497-4538 (Direct).
15.4 Use of Salt-chlorine generators. Placing a Fastlane in a pool sanitized using a salt-chlorine generator
creates increased risk of a hydraulic system failure and oil leaks. Any Fastlane placed in this type of
environment must be properly bonded, and water chemistry must be closely monitored. As stated in
our warranty, pH levels must be maintained between 7.4 and 7.8, total alkalinity between 80 and 120
ppm, salt chlorine levels below 4000 ppm, and total dissolved solids below 7000 ppm. Failure to
properly bond the Fastlane or maintain proper water chemistry will void the warranty.
15.5 Cathodic Protection Maintenance Program. The Fastlane been fabricated using the finest, most
durable materials and has been designed to meet the most stringent safety standards, including VGB
2008. However, unbalanced water chemistry and salt chlorine generators can shorten the lives of these
materials if the unit has not been properly bonded. Endless Pools has provided a sacrificial anode to
draw any corrosion to itself and away from the Fastlane. To maximize the life span of your Fastlane, it
is imperative that the Fastlane be properly bonded and the sacrificial anode be replaced after is has
given up half its mass. Endless Pools offers a Preventative Maintenance Program.
This program will automatically send you a "sacrificial anode" on a regular basis for a nominal charge
to help prevent product damage due to electrolysis. Enrollment in this program is recommended if the
Fastlane is installed in a pool with a salt-chorine generator. Contact Endless Pools Customer Service
at 800-910-2714 to enroll in this program.
Section 16 FASTLANE CONSIDERATIONS
• The Submerged Suction Outlet Model #29-19 (part # 124011) is certified only for use with the Endless
Pool Fastlane system. It may not be used in any other application.
• This Submerged Suction Outlet Model #29-19 (#124011) may only be installed as described in this
Manual. The Submerged Suction Model #29-19 (part #124011), is 19" in diameter and 29" long and
is constructed of 316L perforated stainless steel. It should be replaced after 25 years using a #2 Phillips
head VGB 2008 SUBMERGED SUCTION 29-19, #124011. FOR USE ONLY WITH FASTLANE®
SWIMMING MACHINE MANUFACTURED BY ENDLESS POOLS, INC. LIFE: 25 YEARS, WALL
ONLY. MAXIMUM FLOW FROM SINGLE 5 HP POWER UNIT WITH ALP2-16 GEAR PUMP
PRESET TO MAXIMUM FLOW OF 4.8 GPM UTILIZING 16" DIAMETER OPEN FLOW
PROPELLER. ENDLESS POOLS, INC. ANSI/APSP-16 2011
• The Submerged Suction Outlet Model #29-19 (part #124011) does not require routine service during the
year or as part of Endless Pool winterizing procedures.
W D
• Before each use verify that the Submerged Suction Model #29-19 (part #124011), including the fasteners,
is undamaged and has not been tampered with.
• Do not use the Fastlane if there is any evidence of damage or tampering. Call the Endless Pools Customer
Service Department at 800 910 2714 immediately. The Submerged Suction Model #29-19 must be se-
cured as described in this Manual before the Fastlane is used again.
• Do not increase the flow through the Submerged Suction Model #29-19 (part #124011) by increasing the
size of the pump.
• Please read and then keep these instructions for future reference.
2 3
If you are using a salt-chlorine generator, please complete the following tasks:
• Remove and inspect your Fastlane unit annually. Once removed, rinse the Fastlane with fresh
water before storing for the off-season.
• Replace the underwater hydraulic motor and submersible hoses every two years.
• Ensure that the fluid level in your power unit is no more than one cup above the float level
switch. This simple procedure ensures that any oil leak is minimized
