Mocka Under Cot Storage Assembly Instructions

Mocka Under Cot Storage

Assembly Instructions

Thank you for your purchase.

Please follow the instructions below for correct assembly.

bolt

locking

x16

nut x16

F F

wheel

Hardware Supplied

Phillips & Flathead screwdrivers required

For quicker assembly, we recommend the

use of a power drill on a low-speed setting.

*W e recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.

Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.

mocka.co.nz | mocka.com.au

dowel

screw

x12

x16

cover

Table of Contents

Do you have a question about the Under Cot Storage and is the answer not in the manual?

Page 1 Mocka Under Cot Storage Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. bolt dowel locking screw nut x16 wheel wheel cover Hardware Supplied Phillips & Flathead screwdrivers required For quicker assembly, we recommend the use of a power drill on a low-speed setting.
Page 2 Mocka Under Cot Storage Assembly Instructions Attach the two side panels [2] to the base panel [1] with 6x bolts (A), 4x Attach the front panel [4] and back panel [3] with 10x bolts (A), 8x dowels (C) dowels (C) and secure with 6x locking nuts (B). Tighten with a and secure with 10 x locking nuts (B).
Page 3 Mocka Under Cot Storage Assembly Instructions Attach 2x wheels (E) and 2x wheels (F) to the underside of panel [1] as Repeat steps 1 to 3 to complete the second box. You’re done, enjoy! shown, using 16x screws (D). Tighten with a screwdriver.
