Brooklyn Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
locking nut
bolt
x16
x16
E
F
small screw
x20
L + R
x4
Hardware Supplied
Phillips & Flathead screwdrivers required
mocka.co.nz | mocka.com.au
C
D
long screw
dowel
x8
x8
G
L + R
x4
WARNING:
W
potential to tip over in certain circumstances, i.e. if a child attempts to
climb up on the furniture or in the event of an earthquake. Accordingly,
we recommend that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device provided should
fit most wall types, but please note that different wall materials may
require different fixing devices from those supplied.
Wall
Safety
Screw
Strap
X
Y
wall
r/washer
anchor
screw
x1
x1
Z
washer
x1
Wall St r ap
Any furniture that is not anchored to a wall has the
1
