Malibu - 4 Drawer 3 Door Mirror Robe
Assembly Instructions - Important: Retain these instructions
In order to prevent overturning, this product must be
used with the 2 wall attachment devices provided
Dimensions
Width - 110.4cm
Depth - 49.8cm
Height - 180.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0330 016 1114
For any other queries please contact the Customer Helpline on: 0345 640 2020
for future reference
WARNING!
More help is available throughout this
booklet by scanning in the QR codes
or typing in the links
918/3636
918/4240
920/0100
791/9314
765/1885
341/1665
320/5015
MADE IN
BRITAIN
Issue 8 - 23/09/22
Advertisement
Related Manuals for Argos Malibu 918/3636
Summary of Contents for Argos Malibu 918/3636
- Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0330 016 1114...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Parts of the assembly will be • We do not approximately 85kgs. easier with 2 people. recommend the Please lift with care. use of power •... - Page 3 Components - Panels Please check you have all the panels listed below Left Drawer Right Drawer 3 Left Drawer Right Drawer Front Front Side Side (DF7359) (DF7362) (WRP-00000092) (WRP-00000093) (53 x 15.7cm) (53 x 15.7cm) (45 x 13cm) (45 x 13cm) Drawer Back (WRP-00000261) (47.8 x 13cm)
- Page 4 Components - Panels Please check you have all the panels listed below 15 Plinth 16 Large Top Rail 17 Small Top Rail (DF7353) (DF5858) (DF7356) (106.95 x 9.2cm) (71.4 x 6cm) (34.05 x 6cm) 18 Front Cross Rail 19 Back Cross Rail 20 Back Rail (DF7354) (DF7355)
- Page 5 Components - Fittings Please check you have all the fittings listed below Drawer Fittings Bag marked ‘Bag 2’ Quickfit dowel Knock-in Peg x 16 (F545) (F171GY) Large locking cam nut (F607) 19mm Screw ( 15mm Screw 13mm Screw x 16 F461) (F284) (F63)
- Page 6 Components - Fittings Individual Fittings Bags Overbalance protector F474) kit ( Handle (FBIC2) x 6 FBIC2GOLD - Dark Oak ONLY FMC - Warm Grey ONLY Pre-mounted F419) hinge ( 436mm long (F427) Drawer Brace (F608) CL Runner 450mm long CR Runner (F609) (F610) DL Runner...
- Page 7 Assembly Instructions Step 1 Use the Drawer Fittings Bag marked ‘Bag 2’ for Steps 1 - 7 Prepare the 4 pair of Panel Assembly drawer sides h�ps://www.youtube.com/watch?v=33kDsSSfxjw Insert a large locking cam nut into the 4 left drawer sides and the 4 right drawer sides Note: The arrow on the locking cam nut must...
- Page 8 Assembly Instructions Step 3 Standard Drawer Box Assembly h�ps://www.youtube.com/watch?v=HclfJdkm-Lg Fit the drawer bases Slide a drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 4 Fit the drawer backs Fit a drawer back between the drawer sides Make sure that the...
- Page 9 Assembly Instructions Step 6 Fit the drawer braces Turn the 4 drawer assemblies over and hook a drawer brace onto the bottom edge of the drawer back Fix it to the drawer front and drawer back using 2 Important: Make sure screws that the drawer assembly is square before fitting...
- Page 10 Assembly Instructions Step 8 Use the Main Fittings Bag ‘Bag 1’ for Steps 8 - end Prepare the divider Fit a rail holder to the divider using 2 screws Insert 2 large locking cam nuts into the divider Push 2 of the quickfit dowels as far as they will go into the divider...
- Page 11 Assembly Instructions Step 10 Fit the base Push the horizontal onto the divider fit it using 2 screws Finished and tighten them using front edge the allen key Polystyrene Note: To make the block assembly easier, place polystyrene blocks from the packaging underneath Polystyrene the panels to raise the...
- Page 12 Assembly Instructions Step 13 Fixing Bottom Mounted Runners h�ps://www.youtube.com/watch?v=Z6lGMy19h7Q Prepare the drawer divider Fit 2 CL runners screw to the drawer divider The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws Finished Finished use the holes that line...
- Page 13 Assembly Instructions Step 14 Fit the drawer divider Push the drawer divider onto the horizontal IMPORTANT: Make sure there are no gaps between the fitted panels. Using a flat-head screwdriver, turn the 2 large locking cam nuts Finished fitted to the drawer front edge divider clockwise as...
- Page 14 Assembly Instructions Step 17 Prepare the right side screw Fit 2 CR runners to the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line Finished up with the other panel front edge...
- Page 15 Assembly Instructions Step 19 Finished front edge Fit the small top rail to the right side Push the small top rail down onto the right side Finished front edge Step 20 Fit the right side Push the right side onto the horizontal Make sure that the small top rail is pushed...
- Page 16 Assembly Instructions Step 22 Fit the back cross rail Push the back cross rail onto the right side IMPORTANT: Make sure there are no gaps between the fitted panels. Using a flat-head screwdriver, turn the Important: Make large locking cam nut sure there is no gap fitted to the back cross between the fitted panels.
- Page 17 Assembly Instructions Step 25 Prepare the plinth Insert 2 large locking cam nuts into the plinth Push 2 of the quickfit dowels as far as they will go into the plinth Tap 2 wooden dowels into the plinth Step 26 Fit the plinth Push the plinth onto...
- Page 18 Assembly Instructions Step 28 Prepare the left side screw Fit 2 CL runners to the left side The 1st screw uses the 1st hole in from the Finished front edge front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 19 Assembly Instructions Step 29 Fit the back rail Push the back rail onto the divider IMPORTANT: Make sure there are no gaps between the fitted panels. Using a flat-head screwdriver, turn the large locking cam nut Note: Support the fitted to the back rail back rail until the left clockwise as far as it side has been fitted...
- Page 20 Assembly Instructions Step 31 Fit the top Push the top onto the assembly. IMPORTANT: Make sure there are no gaps between the fitted panels. Using a flat-head screwdriver, turn the 6 large locking cam nuts clockwise as far as they will go to secure the panels.
- Page 21 Assembly Instructions Step 33 Squaring up a Robe and fitting the Back Panel www.youtube.com/watch?v=udEKmXmPEW0 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by Note: Do not making sure that...
- Page 22 Assembly Instructions Fixing Bottom Mounted Runners Step 35 h�ps://www.youtube.com/watch?v=Z6lGMy19h7Q Fit the hanging rail and the drawers Push the hanging rail into the rail holders Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position.
- Page 23 Assembly Instructions Step 37 Fit the shelves Lower the 3 loose shelves down onto the shelf studs Pre-mounted Hinge Fitting & Adjustment Step 38 h�ps://www.youtube.com/watch?v=b4NeCGnpjP8 Prepare the 3 doors Push fit 3 hinges into the left door , the right door and the mirror door...
- Page 24 Assembly Instructions Step 39 Pre-mounted Hinge Fitting & Adjustment https://www.youtube.com/watch?v=b4NeCGnpjP8 Fit the doors and the handles When the hinges have Press the screws into been pushed in, 2 people are needed the holes in the panels tighten up their screws here Fit 1 door at a time, by lining up...
- Page 25 Assembly Instructions Step 40 Pre-mounted Hinge Fitting & Adjustment h�ps://www.youtube.com/watch?v=b4NeCGnpjP8 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown.
- Page 26 Assembly Instructions Step 41 Fit the door buffers Stick a door buffer onto the top corner of each door about 50mm in from the edge. Stick a door buffer onto the bottom corner of each door about 50mm in from the edge.
- Page 27 Assembly Instructions Step 42 WARNING! In order to prevent overturning Fit the 2 overbalance protector kits this product must be used with the 2 wall attachment devices provided To prevent possible overbalancing this unit must be secured to a suitable wall by fitting of the 2 overbalance protector kits to the...
-
Page 28: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
